Best WTD9M48SB
Authorized
Dealer

Best
WTD9M48SB
48 Inch Outdoor Wall Mount Range Hood with Modular Internal Blower System (Blower Sold Separately), Infinite Speed Rotary Control, Illuminated On/Off Rocker Switch, Last Memory Setting, Heat Sentry™, and Dishwasher-Safe Baffle Filters

Top Quality Store on Google
quick specs
Style: Chimney Style
Venting Type: Ducted
Blower Included: No
Blower Type: Sold Separately
Width: 47 7/8 Inch
Depth: 30 Inch
Height: 15 Inch
WiFi: No
Remote Control: No
CFM: 1,300 CFM
Noise Level: 2 Sones
Duct Size: 10 Inch
Dishwasher Safe Filters: Yes
Lights: LED
View more
$2,199.00
MSRP: $2,399.00
You save $200.00
OR
FREE Delivery Available
In stock
In Stock Items labeled IN STOCK will ship within 2 business days from our East Coast warehouse. Actual delivery times will vary based on your location. If you are ordering multiple items and not all items are IN STOCK, the order will ship when all items are available unless you select the SPLIT SHIP option in checkout. IN STOCK may not apply to multiple quantities of the same product.
Have questions? Chat with us!

Recommended Accessories & Add-ons

Product Information
Brand: Best
Model: WTD9M48SB
Appearance
Style: Chimney Style
Type: Hood
Color: Stainless Steel
Trim Color: Stainless Steel
Fingerprint Resistant: No
Glass Canopy: No
Mounting Type: Wall Mount
Venting Type: Ducted
Blower Included: No
Blower Type: Sold Separately
Dimensions
Width: 47 7/8 Inch
Depth: 30 Inch
Height: 15 Inch
Smart
WiFi: No
Bluetooth: No
Alexa: No
Google Home: No
Remote Control: No
Remote Monitoring: No
Remote Diagnostics: No
Dash Replenishment: No
Smart Accessory Required: No
AI Technology: No
Capacity
CFM: 1,300 CFM
Noise Level: 2 Sones
Duct Size: 10 Inch
Features
Filter Type: Baffle
Dishwasher Safe Filters: Yes
Lighting Levels: 1
Lights: LED
Tunable Lighting: No
Technical Details
ADA Compliant: No
Energy Star Rated: No
Voltage: 120 Volts
Approved for Outdoor Use: Yes
GTIN
UPC: 026715258505
EAN: 0026715258505
Are you a Trade Pro? Join Now

Description

48 Inch Outdoor Wall Mount Range Hood with Modular Internal Blower System (Blower Sold Separately)
This UL-Rated Outdoor Chimney Hood is 30 inches deep for even greater capture. The 1300 Max CFM blower (model P12NA sold separately) ensures this chimney hood will handle the heat and smoke created by outdoor grills. Controls are designed to resist the effects of heat and moisture. UL listed for use in damp locations.

Specifications

Product Details
Series:
WTD9M
Product Type:
Outdoor Chimney Range Hood
Installation Type:
Wall Mount
Venting Type:
Ducted
Duct Orientation:
Vertical
Duct Size:
10" Round
Finish:
Grade 304 Stainless Steel
Blower Type:
Internal (Sold Separately)
Compatible Blower:
P12NA
Maximum Blower CFM:
1300
Sound Level:
2.0 Sones (Normal Setting)
Control Type:
Infinite Speed Rotary Control
On/Off Control:
Illuminated Rocker Switch
Last Memory Setting:
Yes
Heat Sentry™:
Yes
Lighting Type:
LED
Number of Lights:
2
Lighting Levels:
1
Bulbs Included:
Yes
Filter Type:
Stainless Steel Baffle
Number of Filters:
4
Dishwasher-Safe Filters:
Yes
Grease Rail:
Yes
Wi-Fi Enabled:
No
Delay Off:
No
Filter Clean Reminder:
No
Outdoor Rated:
Yes
UL Listed for Damp Locations:
Yes
ENERGY STAR® Certified:
No
ADA Compliant:
No
Recommended Mounting Height:
36" Above Cooking Surface
Decorative Flues:
Optional (AEWTD915SB, AEWTD1629SB, AEWTD3057SB)
Backdraft Damper:
Not Included
Electrical Details
Electrical Requirements:
120V / 60Hz / 7 Amps
Electrical Connection:
Direct Wire
Dimensions
Hood Width:
48"
Actual Width:
47 7/8"
Depth:
30"
Height:
15"

Features

Modular Internal Blower System (Blower Sold Separately)
  • Allows you to choose the compatible blower that best suits your ventilation needs.
Infinite Speed Rotary Control
  • Provides smooth, precise adjustment of fan speed for optimal airflow.
Illuminated On/Off Rocker Switch
  • Offers simple operation with a lighted switch for easy visibility.
Last Memory Setting
  • Automatically restores the previously selected fan speed when turned back on.
Heat Sentry™
  • Detects excessive heat and automatically adjusts blower speed to help protect the hood.
Dishwasher-Safe Baffle Filters
  • Stainless steel baffle filters are removable and dishwasher-safe for easy cleaning.
Corrosion-Resistant Grade 304 Stainless Steel
  • Durable construction resists corrosion and is built to withstand outdoor environments.
30" Deep Canopy
  • Provides extended coverage to effectively capture smoke, steam, and cooking odors.
Compatible with P12NA Internal Blower
  • Designed to work with the optional P12NA internal blower for powerful ventilation.
Up to 1300 Max CFM
  • Delivers high-performance ventilation to quickly remove smoke, grease, and odors.
2.0 Sones (Normal Setting)
  • Operates quietly at normal fan speed for a more comfortable cooking environment.
Grease Rail
  • Collects excess grease to help keep the hood cleaner and simplify maintenance.
Vertical Duct Orientation
  • Supports vertical duct installation for efficient exhaust performance.
10" Round Duct Connector
  • Fits a standard 10-inch round duct for secure ventilation installation.
Decorative Flues Available Separately
  • Optional flues provide a finished, built-in appearance for different ceiling heights.
Key Features
Heat Sentry™
Our exclusive Heat Sentry™ feature senses excessive heat and automatically increases the blower speed to high, protecting your range hood from overheating and extending its lifespan.
