Overview
Cooktop Control Type:
Knobs
Surface Burner/Element Rating
Left Front:
3,700-watt boost/2,300 watts
Left Rear:
3,700-watt boost/2,300 watts
Right Front:
3,700-watt boost/2,300 watts
Right Rear:
3,700-watt boost/2,300 watts
Accessories
Included Accessory:
Island Trim (shipped standard with 30" range)
BG8530SS:
8"H. backguard for 30" range
HS24530SS:
High shelf for 30" range
P24CSTSS:
Countertop side trim (2 pieces)
P30CRTSS:
Countertop rear trim for 30" range
P30CBF4SS:
Curb base and custom curb base front for 30" range
Electrical Specifications
Electrical Requirements:
240-208VAC, 60 Hz electrical connection box on product, connect with locally supplied 3-wire, flexible cord or "pigtail rated 40 amp 125-250VAC minimum. Cord must be agency approved for use with household electric ranges.
Maximum Amp Usage:
240V - 54.9 amps; 208V - 51.7 amps
Dimensions & Weight
Overall Height from Bottom:
To top of glass frame - minimum 35 7/8"; to maximum 37"; legs adjust 1 1/8"
Additions to Base Height:
To top of island trim - add 1"; to top of backguard - add 8"; To top of high shelf - add 23 1/2"
Overall Depth from Rear (to end of side panel):
24 5/16"
Overall Depth from Rear (to front of door):
3/4"
Overall Depth from Rear (to end of door handle):
28 11/16"
Oven Interior Overall Width:
25 5/16"
Oven Interior Height:
16 1/2"
Oven Interior Depth:
19 1/2"
Warranty
2-Tear Full:
Complete product
90-Day Full:
Cosmetic parts such as glass, painted items, and decorative items
5-Year Limited:
All gas burners, electric elements (Dual Fuel)
