Overview
Total Capacity:
6.1 Cu. Ft.
Right Oven Capacity:
4.0 Cu. Ft.
AHAM Standard:
3.7 Cu. Ft.
Left Oven Capacity:
2.1 Cu. Ft.
AHAM Standard:
2.0 Cu. Ft.
Cooktop Control Type:
Knobs
Interior Oven Light:
Yes, Halogen
Included Accessory:
Island Trim (shipped standard with 48" range)
Surface Burner Rating
Natural Gas:
15,000 BTU (4.4 kW); 18,500 BTU (5.4 kW)
LP:
12,500 BTU (3.7 kW); 16,600 BTU (4.9 kW)
Griddle Burner Rating
Natural Gas:
15,000 BTU (4.4 kW)
Liquid Propane:
12,500 BTU (3.7 kW)
Oven Burner Rating
Broil Burner:
18,000 BTU NAT./16,000 BTU LP (5.3 kW NAT./4.7 kW LP)
Bake Burner Right Oven:
30,000 BTU NAT./LP (8.8 kW NAT./LP)
Bake Burner Left Oven:
15,000 BTU NAT./LP (4.4 kW NAT./LP)
Optional Accessories
BG8548SS:
8" H. backguard for 48" range
HS24548SS:
High shelf for 48" range
P24CSTSS:
Countertop side trim (2 pieces)
P48CRTSS:
Countertop rear trim for 48" range
P48CBF4SS:
Curb base and custom curb base front for 48" range
LPKPDR:
LP/Propane Conversion Kit
CBC12G:
Bamboo Cutting Board
Electrical Specifications
Requirements:
120VAC/60Hz; 4 ft. (121.9 cm), 3-wire cord with grounded 3-prong plug attached to product
Maximum Amp Usage:
2.0 amps
Dimensions & Weight
Overall Height from Bottom:
To top of side trim - minimum 35-7/8" to maximum 37"; legs adjust 1-1/8"
Additions to Base Height:
To top of island trim - add 1"; to top of backguard - add 8"; to top of high shelf - add 23 1/2"
Overall Depth from Rear:
To end of side panel - 24 5/16"; to front of door - 25-3/4"; to end of door handle - 28-11/16"
Oven Interior Width (right):
23"
Oven Interior Height (right):
16 1/8"
Oven Interior Depth (right):
18 3/4"
Oven Interior Width (left):
12 1/8"
Oven Interior Height (left):
16 1/8"
Oven Interior Depth (left):
18 3/4"
Approximate Shipping Weight:
575 lbs
Warranty
2-Year Full:
Complete product
90-Day Full:
Cosmetic parts such as glass, painted items, and decorative items
5-Year Limited:
All gas burners, electric elements (Dual Fuel)
