Overview
Color Customization:
Available in Selected Colors and RAL Classic Shades
Fuel Conversion Kit Included:
Yes
Cooktop
Cooktop Configuration:
7 Sealed Burners + Integrated Dual-Burner Griddle + Integrated French Top
Burners Beneath Griddle:
2
Burner Type:
Sealed Black Brass Burners
Highest Burner Output:
25,000 BTU
Burner 1 Output:
25,000 BTU - 900 BTU (Double-Ring Dual Burner)
Burner 2 Output:
10,500 BTU - 2,000 BTU (Big Burner)
Burner 3 Output:
10,500 BTU - 2,000 BTU (Big Burner)
Burner 4 Output:
10,500 BTU - 3,100 BTU (Oval Burner)
Burner 5 Output:
7,000 BTU - 1,400 BTU (Small Burner)
Burner 6 Output:
10,500 BTU - 2,000 BTU (Griddle Back)
Burner 7 Output:
7,000 BTU - 1,400 BTU (Griddle Front)
French Top Output:
5,500 BTU
Grate Material:
Cast Iron
Griddle:
Yes, Integrated Dual-Burner Griddle
Ovens
Total Oven Capacity:
5.8 Cu. Ft.
Primary Oven Capacity:
3.5 Cu. Ft.
Secondary Oven Capacity:
2.3 Cu. Ft.
Primary Oven Type:
UOV 80 E3 TFT S
Secondary Oven Type:
UOV 60 E3 TFT
Primary Oven Convection:
European Convection
Secondary Oven Convection:
European Convection
Primary Oven Temperature Range:
85°F to 575°F
Secondary Oven Temperature Range:
85°F to 575°F
Display Type:
4.3" TFT Touchscreen
Electronic Temperature Control:
Yes, Both Ovens
Temperature Probe:
Yes, Primary Oven
Steam Discharge:
Yes, Both Ovens
Controlled Dry or Moist Cooking:
Yes, Both Ovens
Rotisserie:
Yes, Primary Oven
Automatic Shut-Off:
Yes, With Timed Cooking
Soft-Close Oven Doors:
Yes
Primary Oven Interior Lights:
2
Secondary Oven Interior Lights:
2
Automatic Light with Door Opening:
Yes, Both Ovens
Cleaning Type:
Easy Clean Enamel
Primary Oven Interior Width:
26 3/8"
Primary Oven Interior Height:
14 3/8"
Primary Oven Interior Depth:
16 1/8"
Secondary Oven Interior Width:
18 3/16"
Secondary Oven Interior Height:
14 3/16"
Secondary Oven Interior Depth:
16 1/8"
Oven Functions
Pizza Function:
Yes, Both Ovens
Intensive Cooking:
Yes, Both Ovens
Quick Preheat:
Yes, Both Ovens
Moist Intensive Cooking:
Yes, Both Ovens
Fan Grill Cooking:
Yes, Both Ovens
Closed-Door Grilling:
Yes, Both Ovens
Top Heat Cooking:
Yes, Both Ovens
Moist Top Heat Cooking:
Yes, Both Ovens
Bottom Heat Cooking:
Yes, Both Ovens
Moist Bottom Heat Cooking:
Yes, Both Ovens
Static Cooking:
Yes, Both Ovens
Moist Static Cooking:
Yes, Both Ovens
Multiple Fan Cooking:
Yes, Both Ovens
Multiple Moist Fan Cooking:
Yes, Both Ovens
ECO Cooking:
Yes, Both Ovens
Convenience Features
Independent Warming Drawer:
Yes
Soft-Close Warming Drawer:
Yes
Cooking Probe:
Yes, Primary Oven
Tangential Cooling Ventilation:
Yes, Both Ovens
High-Density Insulation:
Yes, Both Ovens
Fold-Down Grill Element:
Yes, Both Ovens
Electrical
Total Electrical Rated Input:
7.85 kW
Primary Oven Maximum Input:
3.7 kW
Secondary Oven Maximum Input:
3.5 kW
Dimensions
Depth with Handle:
29 1/4"
Height with Backsplash:
38 7/8"
Depth with Door Open 90°:
42 5/8"
Certifications
California Proposition 65:
Yes
Warranty
Parts and Labor Warranty:
2 Years
