Description
30 Inch Bottom Freezer Refrigerator Column with 18.1 cu. ft. Total Capacity
The TR-30RBF-R-SG-A is a 30" refrigerator with a bottom freezer and a stainless glass door. It features environmentally friendly R600a hydrocarbon refrigerant, a 300-series stainless steel interior and exterior, and robust hinges tested for over one million door openings. The unit has ramp-up, showcase interior LED lighting, a balanced refrigeration system with cascade airflow, and a built-in ice maker capable of producing up to 3 lbs of prism-shaped ice per day with a 5 lbs storage capacity. This model also boasts a dual evaporator and dual compressor, allowing dedicated cooling systems for each zone, and an energy-efficient, Low-E, triple-pane thermal glass door.
Specifications
Capacity
Total Capacity (cu. ft.):
18.1
Capacity (cu. ft.) - Refrigerator:
14.0
Capacity (cu. ft.) - Freezer:
4.1
Details
Number of Shelves and Type:
2 adjustable/ removable stainless steel encapsulated
Number of Drawers:
2 full-extension/full-width drawers
Number of Freezer Drawers:
2 tiered drawers with nested pull-out drawers and top shelf
Temperature. Range - Refrigerator:
33˚F - 42 ˚F
Temperature. Range - Freezer:
-4˚F - 4˚F
Flow Rate (gpm/lpm):
0.5 / 1.89
Operating Pressure psi (kPa):
30 (207) - 100 (689)
Incoming Water Temperature:
33 - 100˚F (0.6 - 38˚C)
Annual Energy Consumption (kwh):
588
Power Cord Length (ft.):
9
Water Supply:
¼" O.D. braided stainless steel or PEX tubing (¼" O.D. lines and fittings not included). Note: Copper line is not recommended
Electrical Specifications
Dimensions & Weight
Cutout Width Flush Opening:
30 1/4"
Cutout Depth Flush Opening:
26"
Cutout Height Flush Opening:
84 1/4"
Cutout Width Standard Opening:
29 1/2"
Cutout Depth Standard Opening:
24"
Cutout Height Standard Opening:
83 3/4"
Warranty
Parts & Labor:
3 year full
Parts & Labor:
6 year sealed system
Parts Only - sealed system on registered products:
7-12 year
Features
18.1 cu. ft. Total Capacity
- Spacious interior offering ample room for all your groceries and beverages.
Built-in Ice Maker
- Produces up to 3 lbs./day of prism-shaped ice with 5 lbs. storage capacity.
2 Tiered Freezer Drawers
- Maximizes storage efficiency by providing organized compartments for frozen foods.
Balanced Forced-Air Refrigeration System
- Enables proper airflow and even temperature throughout to keep food fresh.
2 Adjustable/Removable Glass Shelves
- Customize your storage space to accommodate tall items or arrange shelves as needed.
1 Fixed Glass Shelf
- Additional stable storage for smaller items and condiments.
2 Full-Extension Drawers
- Easy access to fruits, vegetables, and other perishables with smooth gliding drawers.
R600a
- Environmentally friendly, R600a hydrocarbon refrigerant that improves performance and efficiency while ensuring quiet operation.
Interior LED Lighting
- Ramp-up, showcase interior LED lighting provides amazing illumination throughout.
Beautifully Crafted Glass Door
- Beautifully crafted glass door with stainless steel frame, 120˚ stay-open feature, and ergonomically designed, robust, tubular handles.
- Adds a touch of elegance to your kitchen while allowing you to showcase your favorite items.
Dual Evaporator and Dual Compressor
- Enable dedicated cooling systems for each zone.
Additional Features
- Industry-exclusive, 300-series stainless steel interior and exterior.
- All stainless steel, beautifully crafted proud hinges pass True's rigorous one million door opening test.
- Commercially inspired lift-up grill on top of the unit with toe kick that complements the look of True's undercounter units.
- Intuitive True Precision® Control and readout provides digital accuracy and easy operation.
- Energy efficient, Low-E, double pane thermal glass door.
