Description
20 Inch Freestanding Electric Range with 4 Coil Elements
Summit Appliance offers a wide selection of American-made household ranges built for long-lasting durability in space-challenged kitchens.
The TEM110C is an apartment-sized Electric Range with a generous 2.46 cu. ft. oven interior that can accommodate large trays. The waist-high broiler is located inside the oven, allowing you to switch functions without moving contents to a separate compartment on the floor. The lower drop-down storage compartment is ideal for keeping pots and pans out of the way in small kitchens.
Designed to meet the most current UL safety standards, this unit features one 8" 950W and three 6" 650W coil elements. These operate at a lower wattage than standard electric ranges, allowing for a slow but steady heating process that will not cycle off. This ADA-Compliant Electric Range has two adjustable oven racks, upfront push-to-turn knobs, a recessed oven door, and an anti-tip bracket for added safety. With its classic style and quality construction, Summit's made-in-the-USA cooking line offers reliable cooking for smaller homes.
Note: This unit does not include a line cord (a standard 40 amp 3 or 4-wire range cord can be installed by your electrician).
Specifications
Overview
Broiler Location:
Inside Oven
US Electrical Safety:
CSA
Voltage/Frequency:
220 V AC/60 Hz
Oven Specifications
Oven Capacity:
2.46 cu. ft.
Cooktop Specifications
Cooktop Surface:
Porcelain
Element #1 Size/Wattage:
6" / 675 W
Element #2 Size/Wattage:
6" / 675 W
Element #3 Size/Wattage:
6" / 675 W
Element #4 Size/Wattage:
8" / 950 W
Dimensions & Weight
Oven Interior Height:
14"
Warranty
Parts & Labor Warranty:
1 Year
Features
4 Coil Elements
- The 3 standard 6" and one large 8" element operate at lower wattage than standard electric ranges, allowing for a slow but steady heating process that will not cycle off
2.46 cu. ft. Oven Capacity
- A generous oven interior that can accommodate large trays
Storage Drawer
- Bottom drop-down compartment is ideal for storing cookware, helping to free up space in your small kitchen
Push-To-Turn Burner Knobs
- Burner knobs require a small amount of force to turn on for added protection against accidents; oven knob is not push-to-turn
Upfront Controls
- All knobs are located in the front of the range, letting you adjust your heating without reaching over hot burners
Adjustable Oven Racks
- Two wire racks with safety brakes included, with several glide positions to accommodate a variety of sizes
Indicator Lights
- Control panel includes an 'on' light for the oven and burners for added safety when using the range
Waist-High Broiler
- Broiler is located inside the oven, eliminating the need to transfer contents to a separate compartment towards the floor
Broiler Tray Included
- Two-piece porcelain broiler tray with grease well
Chrome Drip Pans
- Each element includes a removable chrome pan for easier cleaning
Safety Burners with Low Wattage Outputs
- Designed to comply with the latest UL safety standards, the elements operate at lower wattage for slower but steadier heating that will not cycle off
Other Features
- Removable Oven Door and Range Top
- Porcelain and Steel Construction
