Capacity
Upper Rack Dish Height Limit:
7.1" (180mm)
Lower Rack Dish Height Limit:
12.5" (320mm)
Rack And Basket
Fold Down Tines:
Upper: All Foldable, Lower: Half Smart FD & Half Normal FD
Rack Handle/ Deco:
Yes (Upper & Lower)
Rack Color (Body):
Dark Gray
Rack Color (Tine):
Dark Gray
Cup Rack/ Stemware Holder:
Yes
Cup Rack Color:
Cup Rack (Dark Gray), Rubber (Noble Gray)
Height Adjustability:
Easy One Touch (3 Level)
Gliding Type:
Upper & 3rd Rack: Gliding Rail, Lower: Gliding Wheel
Performance
Lower Wash Arm:
QuadWash™
Quad Arm Stainless Steel Deco:
Yes
Quad Arm Body Color:
Pearl Dark Gray
BlastZone™ Bottle Wash:
Yes
SenseClean Wash System:
Yes
No. of Spray Arms:
4 (Top, Upper, Lower, Bottle)
No of Wash Cycles:
5 (Auto, Heavy, Normal, 1-hr, Download Cycle)
No of Options:
5 (Steam, High temp, Dry Boost, Delay Start, Automatic
Detergent and Rinse-Aid Dispenser:
Yes
Drying System:
Dynamic Heat Dry with AOD
End of Cycle Indicator:
Beeper+END indication on display
Safety Float Switch (Leaks):
Yes
Soil (Turbidity) Sensor:
Yes
LoDecibel Quiet Operation:
39dB
Tub Insulation:
Damping Sheet, Sound Absorbing Material (felt), Base
BPA-Free Nylon Coated Racks and Tines:
Yes
Anti-Bacterial Treatment (Drain hose):
Yes
Style And Design
Finishes Printproof™:
Stainless Steel, Essence White
Status Indicators:
Floor Time Display
Remaining Time Indicator:
CycleTrack™ Floor Display
Tub Material:
Stainless Steel
Control Panel:
Top Control (Hidden Display)
Smart Features
Energy/ Water
Energy Use (kWh/year):
220
Water Use (Gallon/Cycle):
2.9
Certification:
UL (Safety), NSF (Sani)
Dimensions/ Clearances/ Weight
Unit Dimensions (WxDxH):
23 3/4" x 23 3/4" x 33 5/8"
Depth with Door Closed (Handle):
23 3/4"
Depth with Door Open:
48 1/2"
Carton Dimensions (WxDxH):
28 1/32" x 29 5/8" x 34 7/8"
Clearances (WxDxH):
24" x 24" x 33 5/8"
Weight (Unit / Carton):
93lbs/ 104 lbs
Container Stuffing Quantity:
140
Limited Warranty
Control Board and Rack Parts:
5 Years
Direct Drive Motor:
10 Years
