Cooktop
Number of Inductor Elements:
4
1 - Power of Back Left Heating Element:
2,200 W / 3,600 W (In Boost)
2 - Power of Front Left Heating Element:
2,200 W / 3,600 W (In Boost)
3 - Power of Back Right Heating Element:
2,200 W / 3,600 W (In Boost)
4 - Power of Front Right Heating Element:
2,200 W / 3,600 W (In Boost)
Power of Left Area + 1A FlexPlus™ Left Heating Element:
3,300 W / 3,600 W (In Boost)
Power of Right Area + 3A FlexPlus™ Right Heating Element:
3,300 W / 3,600 W (In Boost)
Element Size
Dimension of Back Left Heating Element:
8 1/2" x 7 1/2"
Dimension of Front Left Heating Element:
8 1/2" x 7 1/2"
Dimension of Back Right Heating Element:
8 1/2" x 7 1/2"
Dimension of Front Right Heating Element:
8 1/2" x 7 1/2"
Dimension of FlexPlus™ Left Heating Element:
3 1/2" x 11 1/4"
Dimension of FlexPlus™ Right Heating Element:
3 1/2" x 11 1/4"
Oven
Oven Capacity:
4.4 cu. ft.
Cooking Modes:
Bake, Convection Bake, True Convection, Convection Roast, Roast, Convection Broil, Broil, Meat Probe
Convection Power:
2,750 W
Cavity Interior Dimensions (HxWxD):
16 1/4" x 25" x 18 5/8"
Cavity Usable Dimensions (HxWxD):
12" x 22 3/8" x 16 5/8"
Technical Details
Home Connect® (Wi-Fi Enabled):
Yes
Volts:
240 / 208 V, 60Hz 4 Wire
Power Cord Length:
Purchase Separately
Dimensions & Weight
Overall Appliance Dimensions (HxWxD):
35 3/4" - 36 3/4" x 29 15/16" x 24 3/4"
Required Cutout Size (HxWxD):
35 3/4" - 36 3/4" x 30" x 24"
Warranty
Limited Warranty, Entire Appliance, Parts and Labor:
2 Year
Accessory
Accessories Included:
1 Telescopic Rack, 2 Standard Racks, Meat Probe, 1 Lg. Broil Pan, Island Trim
Accessories Optional
CHEFSPAN13:
16" Round Skillet
CHEFSPAN08:
10" Stainless Steel Pan
TGRILLPANX:
Non-Stick Induction Grill 9" x 17"
PARKB3XIHB:
Metallic Blue Knob Kit
TROASTERT:
Stainless Steel Roaster Pan 10" x 16"
TEPPAN1016:
Griddle Style Teppanyaki 10" x 16"
TEPPAN1013:
Teppanyaki 10" x 13"
