Rangetop
Total Number of Cooktop Burners:
6
Total Number of Cooktop Grill:
1
Power of Back Left Burner BTU:
15,000 and XLO
Power of Front Left Burner BTU:
22,000 and XHI / XLO
Power of Back Center Burner BTU:
15,000
Power of Front Center Burner BTU:
18,000
Power of Center 12" Electric Grill:
1,630 W (6-Pass 2x)
Power of Back Right Burner BTU:
15,000 and XLO
Power of Front Right Burner BTU:
18,000 and XLO
Oven
Oven Capacity (Lg/Sm):
5.7/2.5 cu. ft.
Cooking Modes Large Cavity:
Bake, Convection Bake, Keep Warm, Roast, Broil
Cooking Modes Small Cavity:
Bake, Convection Bake, Proof, Roast, Broil
Self-Clean (Lg/Sm):
Yes/Yes
Telescopic Rack(s) (Lg/Sm):
3/2
Interior Lights (Lg/Sm):
2/1
Bake Power (Lg/Sm):
23,700 BTU/15,000 BTU
Broil Power (Lg/Sm):
17,500 BTU/7,000 BTU (Both Infrared)
Home Connect™ (Wi-Fi Enabled):
Yes, Large Oven Only
Large Cavity Interior Dimensions (HxWxD):
16 1/4" x 28" x 21 1/2"
Large Cavity Usable Dimensions (HxWxD):
11 1/4" x 25 3/8" x 19 1/2"
Small Cavity Interior Dimensions (HxWxD):
16 1/4" x 12 3/8" x 21 1/2"
Small Cavity Usable Dimensions (HxWxD):
11 5/8" x 9 3/4" x 19 1/2"
Dimensions and Weight
Overall Appliance Height:
35 3/4"-36 3/4"
Overall Appliance Weight:
47 15/16"
Overall Appliance Depth:
27 7/8"
Required Cutout Size Height:
35 3/4" - 36 3/4"
Required Cutout Size Weight:
48"
Required Cutout Size Depth:
24" - 25 1/8"
Technical Details
Fuel Subtype:
Natural Gas
Warranty
Limited Warranty, Entire Appliance, Parts and Labor:
2 Year
Accessories Included
2 Sm. Telescopic Racks:
Yes
Multi-Point Meat Probe:
Yes
1 Bx. Ceramic Briquettes:
Yes
