Product Specifications
Style:
Built-In Top Control
Exterior Style:
Custom Panel
Number of Place Settings:
16
Wash System:
3-Level, 700 Series
Tub and Door Liner:
Stainless Steel
Dispenser:
Rinse Aid with Indicator and Adjustment
Leveling System:
4 Leveling Legs
Wash Features
Dishwasher Cycles:
1 Hour Wash, AutoSense, Cascade Platinum Plus (On App), Custom (Assigned To Rinse - Reassignable On App), Heavy Wash, Normal Wash
Dishwasher Options:
Bottle Jets, Child Lock (On App), Connect+ (Assignable On app), Delay Start 1-12 Hr., Dry Boost (High), Dry Boost (Normal), Dry Boost (Off), FilterFresh (On App), Sabbath Mode, Sani (Certified to NSF Standard 184), Start/Cancel, Steam PreWash, Wash TempBoost, Wash Zones/Half Load (On App)
Dishwasher Drying Features:
Dry Boost, Multi-Wattage Wash & Dry Element, Normal, High, Off
Smart
Smart Home App Compatible:
Yes
Smart Home Device Compatible:
Smart Features powered by SmartHQ
Connected Capabilities:
Amazon Alexa, Google Home
Racks and Baskets
Racking System:
Full 3rd Rack
Top Rack/3rd Rack:
3rd Rack + Caddy
Upper Rack:
1 Blue Rack Handle Treated with Microban Antimicrobial Technology, Ball-Tip Tines, Smooth Glide Upper Rack
Lower Rack:
1 Blue Rack Handle Treated with Microban Antimicrobial Technology, Ball-Tip Tines
Cutlery Tray:
One-piece Removable 3rd Rack
Rack Features:
1-Piece Silverware Basket with 3 Cell Covers, Adjustable Upper Rack, Ball-Tipped Tines, Blue Cell Covers Treated with Microban Antimicrobial Technology, Fold-Down Tines - Lower
Features
Additional Protection:
Active Flood Protect
OdorBlock Capabilities:
Microban + FilterFresh
Microban Antimicrobial Treated Surfaces:
Yes - Control Panel, Interior Rack Handles, Silverware Basket Cell Covers, Fine & Ultra Fine Filters
Control Type:
8 Touchpads, Fingerprint Resistant Cap Touch Controls, Top Controls
Dishwasher Control Features:
3 Digit Display with Cycle Countdown, Audible End-of-Cycle Signal, Cycle Progress Indicators: Clean/Sanitized/Smart Assist/Wi-Fi/Remote Enabled, Last Cycle Memory, White LEDs
Water Filtration System:
100% Filtration with Piranha Hard Food Disposer and Removable Filter, Blue Filters Treated with Microban Antimicrobial Technology
Wash System Features:
90+ Spray Jet Wash System, Automatic HotStart, Automatic Temperature Control, Bottle Jets (4), Deep Clean Silverware Jets, Drain Pump, Piranha Hard Food Disposer with Removable Filter, Variable Speed Dual Pumps and Motors
Wash Arms:
3 Wash Levels, Bottle Jets, Deep Clean Silverware Jets, Lower, Middle, Upper
Economical / Quiet
Motor Type:
Variable Speed
Outer Wrap:
Bitumen, Full-wrap Blanket
Quiet Features:
44 dBA Based On Results From Base Model PDT715SYVFS, Quiet Water Valve, Sealed Toe Kick, Tub Collar Trim
Door Insulation:
Insulation, Mastic
Power / Ratings
Electrical Requirements:
120V ; 60Hz ; 6.6A
Volts/Hertz/Amps:
120V; 60Hz; 6.6A
Energy Consumption (kWh/year):
240
Calrod Heater Watts:
800/500
Power Connection:
Optional Cord Kit (GPFCORD - WX09X70910, WX09X70911)
Appearance
Installation:
Built-Up Floor Capable, Flush Cabinet Installation, Side Installation or Top Installation Included
Color Appearance:
Custom Panel and Handle Required
Handle:
Custom Handle Required - Not Included with Unit
Door Style:
Long Door with Top Controls
Door Appearance:
Full-length Door
Control Panel Color:
Matte Onyx Black treated with Microban™ Antimicrobial Technology
Weights & Dimensions
Approximate Shipping Weight:
118 lbs.
Depth with Door Open:
27 1/2"
Depth Without Handle:
24"
Height w/Legs Extended - Maximum Height:
34 5/8"
Height w/ Legs Retracted - Minimum Height:
33 3/8"
Accessories
Optional 12' Drain Hose:
Optional Hose Kit (WD24X10065)
Warranty
Labor Warranty:
Limited 1-year Entire Appliance
Parts Warranty:
Limited 1-year Entire Appliance
Warranty Notes:
See Written Warranty For Full Details
Certificates
