Summary
Type:
Electric Single Oven Slide-in
Capacity
Oven Capacity (cu. ft.):
6.3 cu.ft.
Storage Drawer Capacity (cu. ft.):
0.8 cu.ft.
Cooktop
Element Size/Wattage - Center:
1800 (Boost) / 1300 (Normal) (6")
Element Size/Wattage - Left Front:
3300 (Boost) / 1650 (Normal) (7")
Element Size/Wattage - Left Rear:
3300 (Boost) / 1650 (Normal) (7")
Element Size/Wattage - Right Front:
4300 (Boost) / 2400 (Normal) (11")
Element Size/Wattage - Right Rear:
100 (6")
Hot Surface LED Indicator:
Yes
Type:
Induction + Radiant
Oven Features
Broil Element:
Sheath (4.2KW)
Convection (Watt):
Sheath 2500W
Convection Conversion:
Yes
Convection Fan:
(BLDC (DC 24V/500~2600rpm), forward and reverse rotation)
Convection Type:
Dynamic ProBake® Convection
Oven Modes:
Bake, Conv. Bake, Conv. Roast, Broil High, Broil Low, Warm, Proof, Frozen Meal, Air Fry, Air Sous-Vide, Air Roast, Pizza, Crispy Reheat, Dehydrate, Auto cook, EasyClean®, Self Clean
Appearance
Handle Material:
Aluminum
All Available Colors:
PrintProof™ Stainless Steel
Cooktop Finish:
Black Ceramic + Gray Pattern
Oven Door Feature:
WideView™ Window
Drawer Features
Controls
Automatic Safety Shut-Off:
Broil, Warm, Pizza : After 3 hours Air sous-vide : After 48 hours Esc : After 12 hours
Clock:
12 hr or 24 hr (option)
Cooking Complete Reminder Volume:
Beeper (Hi, Lo, Off)
Cooktop Control Type:
Front Control Knobs
Display:
6.8" Color TFT LCD
Language:
English/Spanish/Franch
Oven Control Type:
Glass Touch (SmoothTouch™)
Temperature Unit of Measure:
Fahrenheit / Celsius
Accessories
Cooktop Cream/Cleaner:
Yes
Cooking Appliance ThinQ® Smart Features
3rd Party Recipe App:
Sidechef
Power/Ratings
Energy Star® Certified:
Yes
Amp Rating at 208V:
52.7A
Amp Rating at 240V:
54.0A
KW Rating at 208V:
10.2kW
KW Rating at 240V:
12.1kW
Required Power Supply (amp):
40A
Dimensions/Clearances/Weight
Carton Dimensions (in) (W x H x D):
32 1/2" x 44" x 30 1/2"
Drawer Dimensions (in) (W x H x D):
22 3/16" x 4 1/2" x 16 3/8"
Height to Cooking Surface (in):
36"
Oven Interior Dimensions (W x H x D):
24 7/8" x 21 3/8" x 20"
Overall Depth (in) - including handle:
29.3125"
Overall Height (in):
36.5"
Overall Width (in):
29.875"
Shipping Weight:
233.3 lbs.
Product Weight:
199.7 lbs - Acc. not included, 210.3 lbs - Acc included
