Brand:
LG
Model:
LMDN186HV
Width:
38 11/32 Inch
Depth:
33 27/32 Inch
Height:
7 15/32 Inch
Net Weight:
51 Lbs.
Shipping Weight:
57 Lbs.
BTU Class:
18,000 BTU
Heating Capacity:
20,800 BTU
Cooling Capacity:
18,000 BTU
AC System Type:
Mini Split
Component Type:
Indoor Unit
Operation:
Cooling with Heat Pump
Placement Type:
Concealed Duct
Wireless Remote Control(s) Included:
No
Wired Remote Control(s) Included:
Included
Thermostat Range - Cooling (F°):
57-77
Thermostat Range - Heating (F°):
59-81
Power Source V / Hz / Ø:
(208/230/60/1)
Rated Amps:
0.8 Amps
Fan:
Sirocco
No. of Fans:
3
Motor:
Brushless Digitally Controlled
Motor Drive:
Direct
Energy Star Certified:
No
Airflow Rate Low (CFM):
353 CFM
Airflow Rate Medium (CFM):
441 CFM
Airflow Rate High (CFM):
530 CFM
Operating Sound Level - Low (dB):
31 dB
Operating Sound Level - Medium (dB):
34 dB
Operating Sound Level - High (dB):
36 dB
Temperature Sensor:
Thermistor
Power and Communication Cable - No.:
4
Power and Communication Cable - AWG:
18
Liquid Line Outer Diameter:
1/4 Inch
Suction Line Outer Diameter:
1/2 Inch
Drain Line Outer Diameter:
1 1/4 Inch
Drain Line Inner Diameter:
1 Inch
Refrigerant Type:
R-410A
Refrigerant Control:
EEV
Control Lock Function (Concealed Duct Only):
Yes
Human Detection Technology:
No
Room-Freeze Protection:
No
Filter Clean Notification:
No
Hot Start Heating System (Heat Pumps Only):
No
Program Timer:
No
Manual Power Switch:
No
Defrost/Deicing:
No
Air Filter:
Yes
Filters Washable?:
Yes
Filters Anti-microbial?:
No
Restart Delay:
Yes
Self-diagnosis:
No
Condensate Sensor Connection:
No
Soft Start:
No
Quiet/Sleep Mode:
Yes
Self-Cleaning Indoor Coil:
No
Built-in Drain Pump (Indoor Unit):
Yes
Hidden Display:
No
Surge Cool/Heat:
No
Auto Operation:
Yes
Auto Restart on Power Failure:
Yes
Auto-changeover:
No
Automatic Louver Adjustment:
No
4-Way Swing:
No
Dehumidifying Mode:
Yes
No. of Fan Speeds:
3
ADA Compliant:
No
Voltage:
230/208 Volts
UPC:
048231374408
EAN:
0048231374408
