Overview
Refrigerator:
16.3 cu. ft.
Total Capacity:
24.5 cu. ft.
Temperature Controls:
Electronic/Digital
Auto Closing Door Hinge:
Yes
Water & Ice System
Ice & Water Dispenser:
Yes
In-door Ice Maker Ice Type:
Cubed / Crushed
In-door Daily Ice Production:
2.5 / 2.7 (IcePlus) lbs
In-door Ice storage capacity:
2.3 lbs
Freezer Daily Ice Production:
2.5 / 2.8 (Ice Plus) lbs
Freezer Ice storage capacity:
5.1 lbs
Filtration System:
1 Stage
Dispenser Light Decoration:
No
Fresh Food Section
No. of Shelve:
4 Split (4 Fixed)
Shelf Construction:
Spill protector Tempered glass
Pantry (Glide N Serve:
Yes (Normal)
Light (Back Lit Lighting):
No
Freezer Section
Drawers / Shelves:
2-Tier Organization
Drawer Divider:
Yes (Fixed)
Freezer Light:
Upper LED Lighting
Freezer Light:
Lower Pocket
SmartThinQ® Smart Features
Claims & Certifications
Electrical Specifications
Warranty
Sealed System (Parts & Labor):
5 Years
Compressor (Parts & Labor):
5 Years
Linear Compressor (Parts Only):
10 Years
Dimensions & Weights
Total (WxHxD):
32 15/16" x 69 15/16" x 35 15/16"
Height (Top of Hinge or Door cap Décor:
69 15/16"
Depth (with Handles:
35 15/16"
Width (Door Open 90˚ w/o Handle:
36 11/16"
Case Edge Clearance (Door Fully Open:
54 11/16" (R)10" / (L) 11 15/16"
Width (Door Open 90˚ with Handle):
41 5/8"
Door Edge Clearance with Handle:
4 3/4"
Door Edge Clearance without Handle:
2 1/4"
Height to Top of Case:
68 5/8''
Height (Floor to Top of Freezer Door):
27 5/8"
Depth without Door:
29 1/2"
Depth without Handles:
33 7/16"
Depth (to Hinge Cover):
24 5/16"
Depth (Total with Door Open):
46 11/16"
Depth (Draw Open Fully without Handle):
53 3/16"
Installation Clearance Sides:
1/8", Top 1", Back 2"
Carton Dimensions (WxHxD):
35 1/8" x 71 7/16" x 37 5/8"
Weight (Unit/Carton):
262 lbs. / 276.7 lbs
