Capacity
Upper Rack Dish Height Limit:
7.1"
Lower Rack Dish Height Limit:
12.5"
Racks and Baskets
Fold Down Tines:
Upper: All Foldable, Lower: Half Smart FD & Half Normal FD
BPA-Free Nylon Coated Racks and Tines:
Yes
Height Adjustable:
Easy One Touch (3 Levels)
Rack Color (Handle):
Dark Grey
Rack Color (Tine):
Dark Grey
Cuprack Color:
Cup rack (Dark Gray), Rubber (Noble Gray)
Gliding Type:
Upper: Gliding Rail, Lower: Gliding Wheel, 3rd Rack: Normal Rack
Style and Design
Control Panel Location:
Top Control
Control Panel Material:
ABS
Tub Material:
Stainless Steel
All Available Colors:
Print Proof Stainless Steel, Black Stainless Steel
Status Indicators:
Mood Light
Remaining Time indicator:
LED
Features
Lower Wash Arm:
QuadWash Pro™
Quad Arm Body Color:
Pearl Dark Grey
Quad Arm Nozzle Color:
Orange
Number of Spray Arms:
3 (Top, Upper, Lower)
SenseClean™ Wash System:
Yes
Detergent and Rinse-Aid Dispenser:
Yes
Drying System:
Dynamic Heat Dry with AOD
Number of Wash Cycles:
5 (Auto, Heavy, Normal, 1-Hour, Download Cycle)
Number of Options:
6 (Steam, High Temp, Dry Boost, AOD, Delay Start - Up to 12hrs, Remote)
End of Cycle Indicator:
Yes (Beeper + END indication on display)
Safety Float Switch (Leaks):
Yes
Soil (Turbidity) Sensor:
Yes
LoDecibel™ Quiet Operation:
42 dBA
Tub Insulation:
Yes (Damping Sheet, Sound Absorbing Material (felt), Base
Anti-Bacterial Treatment (Drain hose):
Yes
ThinQ® Smart Features
Power Ratings
ENERGY STAR® Qualified:
Yes
Energy Use (kWh/Year):
220 kWh/Year
Water Use (Gallons/Cycle):
2.9
Dimensions / Clearances / Weight
Product Dimensions (in) (W x H x D):
23 3/4" x 33 5/8" x 26 1/8"
Depth with Door Closed with Handle (in):
23 3/4"
Depth with Door Open (in):
48 1/2"
Clearances (WxDxH):
24" x 24" x 33 5/8"
Carton Dimensions (in):
(W x H x D) 28 1/32" x 29 1/4" x 34 7/8"
Limited Warranty
Control Board and Rack Parts Control Board and Rack Parts:
2 Years
Stainless Tub and Door Liner:
2 Years
Direct Drive Motor:
10 Years
