Brand:
LG
Series:
Art Cool Mirror
Model:
LAN090HSV5
Width:
35 1/4 Inch
Depth:
8 9/32 Inch
Height:
11 3/8 Inch
Net Weight:
20.5 Lbs.
Shipping Weight:
25.6 Lbs.
BTU Class:
9,000 BTU
Heating Capacity:
10,900 BTU
Cooling Capacity:
9,000 BTU
AC System Type:
Mini Split
Component Type:
Indoor Unit
Operation:
Cooling with Heat Pump
Placement Type:
Wall Mount
Wireless Remote Control(s) Included:
Included
Thermostat Range - Cooling (F°):
53-75
Thermostat Range - Heating (F°):
60-86
Power Source V / Hz / Ø:
(208/230/60/1)
Rated Amps:
7.4 Amps
Fan:
Cross-Flow
No. of Fans:
1
Motor:
Brushless Digitally Controlled
Motor Drive:
Direct
Energy Star Certified:
Yes
Moisture Removal (Pts/hr):
2.7 Pts./Hr.
Airflow Rate Low (CFM):
169 CFM
Airflow Rate Medium (CFM):
218 CFM
Airflow Rate High (CFM):
268 CFM
Operating Sound Level - Low (dB):
27 dB
Operating Sound Level - Medium (dB):
32 dB
Operating Sound Level - High (dB):
36 dB
Temperature Sensor:
Thermistor
Entering Mixed Air - Cooling:
57° - 77°F DB
Entering Mixed Air - Heating:
59° - 81°F DB
Power and Communication Cable - No.:
4
Power and Communication Cable - AWG:
18
Liquid Line Outer Diameter:
1/4 Inch
Suction Line Outer Diameter:
3/8 Inch
Drain Line Outer Diameter:
27/32 Inch
Drain Line Inner Diameter:
5/8 Inch
Power Supply Cable - No. x AWG:
3 x 14
Refrigerant Type:
R-410A
Refrigerant Connection Type:
Flare
Refrigerant Control:
EEV
Piping Length (No Additional Refrigerant):
41 Ft.
Min. Line Length - Each:
9.8 Ft.
Min. Line Length - Total:
9.8 Ft.
Max. Line Length - Total:
82 Ft.
Control Lock Function (Concealed Duct Only):
No
Human Detection Technology:
No
Room-Freeze Protection:
No
Filter Clean Notification:
Yes
Hot Start Heating System (Heat Pumps Only):
Yes
Program Timer:
Yes
Manual Power Switch:
No
Defrost/Deicing:
Yes
Air Filter:
Yes
Filters Washable?:
Yes
Filters Anti-microbial?:
No
Restart Delay:
No
Sleep Mode:
Yes
Self-diagnosis:
Yes
Condensate Sensor Connection:
Yes
Soft Start:
Yes
Quiet/Sleep Mode:
Yes
Self-Cleaning Indoor Coil:
Yes
Built-in Drain Pump (Indoor Unit):
No
Hidden Display:
No
Surge Cool/Heat:
Yes
Auto Operation:
Yes
Auto Restart on Power Failure:
Yes
Auto-changeover:
Yes
Automatic Louver Adjustment:
Yes
4-Way Swing:
Yes
Dehumidifying Mode:
Yes
No. of Fan Speeds:
6
WiFi Connected:
Yes
