KitchenAid KOED530SPS - 30 Inch Double Convection Electric Wall Oven with 10 cu. ft. Total Capacity

+16

Image Disclaimer

Authorized

Dealer

KitchenAid

KOED530SPS

30 Inch Double Convection Electric Wall Oven with 10 cu. ft. Total Capacity, Air Fry Mode, Self-Cleaning, Halogen Lighting, True Convection Oven, Automatic Shut-Off, Electronic Touch Control, Integrated Thermometer, Sabbath Mode, and Star-K Certified

Name: KitchenAid KOED530SPS
Brand: KitchenAid
SKU: KOED530SPS
Price: 2798 USD
Availability: InStock
Rating: 4.8 (36 reviews)

4.8

Average rating of
36 reviews

Top Quality Store on Google

Only 9 left in stock

Sale

Buy More Save More

Pair & Save $350 Instantly

quick specs

Microwave: No

Speed Oven: No

Steam Oven: No

Fingerprint Resistant: Yes

Drawer: None

Cutout Width: 28 1/2 Inch

Cutout Depth: 24 Inch

Cutout Height: 50 1/4 Inch

Capacity: 10 Cu. Ft.

Upper Capacity: 5 Cu. Ft.

Lower Capacity: 5 Cu. Ft.

Convection Type: True European

Self-Cleaning: Yes

Undercounter Installable: No

Hurry! This deal expires in:

^$2,798^.00

MSRP: ~~$4,443.00~~

You save $1,645.00

Buy more & save up to $4,800

See all eligible items

$400

$1,000

$1,600

$2,300

$3,600

$4,300

$4,800

Current Offers

AJ EXCLUSIVE: Save $50 instantly on Qualifying Models Expires 09/01/2026 KitchenAid: Buy More Save More Up to $3,000 Expires 09/30/2026 AJ Exclusive: Buy More Save More, Save up to $1,000 Instantly Expires 09/01/2026 AJ Exclusive: Save up to $350 on KitchenAid Cooktop + Wall Oven Purchase Expires 09/16/2026 KitchenAid: Buy More Save More Up to $800 Expires 09/17/2026 KitchenAid: Fit System Limited Guarantee up to $500 Expires 12/31/2026

Have questions? Chat with us!

Recommended Accessories & Add-ons

KitchenAid

30 Inch Induction Cooktop

24 Inch Built-In Undercounter Dual Zone Beverage Center

$2,998.00

Product Information

Brand: KitchenAid

Model: KOED530SPS

Appearance

Fuel Type: Electric

Style: Double

Microwave: No

Speed Oven: No

Steam Oven: No

Door Style: Drop Down

French Door Oven: No

Color: Fingerprint Resistant Stainless Steel

Handle Color: Stainless Steel

Fingerprint Resistant: Yes

Stainless Steel Handle: Yes

Handless: No

Control Type: Touchpad

Viewing Window: Yes

Drawer: None

Clock: Yes

Dimensions

Cutout Width: 28 1/2 Inch

Cutout Depth: 24 Inch

Cutout Height: 50 1/4 Inch

Exterior Width: 29 3/4 Inch

Exterior Depth: 27 1/8 Inch

Exterior Height: 50 13/16 Inch

Depth to Handle: 26 469/500 Inch

Shabbos Compliance

Sabbath Mode: Yes

Certification: STAR-K

Smart

WiFi: No

Capacity

Capacity: 10 Cu. Ft.

Upper Capacity: 5 Cu. Ft.

Lower Capacity: 5 Cu. Ft.

Oven Racks: 4

Upper Racks: 2

Lower Racks: 2

Oven Features

Digital Temperature Display: Yes

Timer: Yes

Convection: Yes

Convection Type: True European

Self-Cleaning: Yes

Interior Oven Light: Yes

Removable Door: Yes

Air Fry: Yes

Sous Vide: No

Push to Open: No

Soft Close: Yes

Technical Details

ADA Compliant: No

Undercounter Installable: No

Approved for Outdoor Use: No

LP Conversion: No

Amps: 40

Voltage: 240 Volts

GTIN

UPC: 883049921730

Description
Specifications
Features
Rebates
Reviews

Description

30 Inch Double Convection Electric Wall Oven with 10 cu. ft. Total Capacity
Get the crisp you crave, right from your oven. KitchenAid® Double Wall Ovens with Air Fry Mode circulate hot air around the included basket to cook with less oil. An integrated thermometer takes the guesswork out of roasting meat just the way you like.

Specifications

Oven Cavity Details

Convection Functions:

Bake, Broil, Air Fry, Convection Conversion

Door Broil Position:

Closed

Broiler Location:

Top of Oven

Number of Broil Elements:

Light Type:

Halogen

Oven Cleaning Type:

Self-Cleaning

Door Removable:

Yes

Number of Lower Oven Racks:

Number of Upper Rack Guides:

Upper Oven Number of Oven Lights:

Number of Bake Elements:

Convection Element Type:

True Convection

Number of Upper Oven Racks:

Lower Oven Number of Oven Lights:

Hidden Bake Element:

Yes

Interior Coating:

Porcelain

Oven Cooking System:

Convection Both

Broiler Element Power:

4000W Both

Bake Element Power:

2800W Both

Convection Element Power:

3200 Both w

Installable Under Cooktop:

Upper Oven Capacity:

5 cu. ft.

Lower Oven Capacity:

5 cu. ft.

Details

Flush Installation Approved:

Yes

Fuel Type:

Electric

Oven Automatic Shut-Off:

Yes

Oven Type:

Double

Exterior Details

Door Type:

Metal & Glass

Door Lock:

Yes

Controls

Control Type:

Electronic Touch

Display Color:

White

Electronic Display Type:

Digital

Language Conversion:

English/French/Spanish

Light Control:

Oven Light Touch Pad

Electrical Requirements

Power Cord Included:

Amps:

Hz:

Volts:

240

Dimensions & Weights

Total Capacity:

10 cu. ft.

Cutout Width:

28 1/2"

Cutout Depth:

24"

Cutout Height:

50 1/4"

Width:

29 3/4"

Depth:

27 1/8"

Depth Closed Excluding Handles:

24 1/2"

Depth Closed Including Handles:

26 469/500"

Depth With Door Open 90 Degree:

46 47/250"

Height:

50 13/16"

Lower Oven Interior Depth:

18"

Lower Oven Interior Height:

25"

Lower Oven Interior Width:

25"

Upper Oven Interior Height:

18"

Upper Oven Interior Width:

25"

Upper Oven Interior Depth:

19"

Common Size:

30"

Maximum Height:

51 1/4"

Net Weight:

305 lbs

Gross Weight:

311 lbs

Certifications

ADA Compliant:

CUL:

Yes

Star K Certified:

Yes

UL:

Yes

Prop 65:

Yes

Features

10 cu. ft. Total Capacity

This oven provides a massive combined cooking volume, split between two 5.0 cu. ft. ovens, offering ample space for large meals or baking multiple dishes at once.

Air Fry Mode

A dedicated setting that circulates hot air around food, delivering crispy, "fried" results with less oil, complete with an included air fry basket.

Self-Cleaning

Utilizes high temperatures to burn away stubborn baked-on food, making oven cleanup easy without harsh chemicals.

Halogen Lighting

Bright halogen lights illuminate the interior of both ovens, allowing you to clearly see your food as it cooks.

True Convection Oven

Features KitchenAid's Even-Heat™ True Convection with a unique bow-tie design and dedicated heating element for consistent, even cooking results in both oven cavities.

Automatic Shut-Off

A safety feature that automatically turns the oven off after a set period of inactivity or extended cooking, preventing overcooking and saving energy.

Electronic Touch Control

Provides a sleek and intuitive digital control panel for easy and precise selection of cooking modes and settings.

Integrated Thermometer

An internal probe that accurately measures the food's temperature and can automatically shut off the oven when your desired doneness is reached.

Sabbath Mode

A Star-K Certified feature that allows the oven to be used on the Sabbath and holidays in accordance with religious observances.

Star-K Certified

This certification confirms the oven's compliance with specific kosher standards, particularly for its Sabbath Mode.

Oven Light Touch Pad

A convenient touch-sensitive control that allows you to turn the oven interior lights on or off easily.

Digital Display

A clear and easy-to-read screen that shows cooking settings, time, temperature, and other important information.

Door Lock

A safety mechanism that locks the oven door, especially important during self-clean cycles or to prevent accidental opening.

Removable Oven Door

Designed to be easily detached from the oven for more thorough cleaning of the door glass and internal components.
