KitchenAid KMMF530PJP - 30 Inch Multifunction Over-the-Range Smart Microwave Oven with 1.1 cu. ft. Capacity
KitchenAid KMMF530PJP - 30 Inch Multifunction Over-the-Range Smart Microwave Oven with 1.1 cu. ft. Capacity
KitchenAid KMMF530PJP - 30 Inch Multifunction Over-the-Range Smart Microwave Oven with 1.1 cu. ft. Capacity
KitchenAid KMMF530PJP - 30 Inch Multifunction Over-the-Range Smart Microwave Oven with 1.1 cu. ft. Capacity
+7

Image Disclaimer

Image Disclaimer
Images shown may depict a product feature or design without fully reflecting the product overall. Please refer to product details and specifications when making a final selection for purchase.
KitchenAid KMMF530PJP
Authorized
Dealer

KitchenAid KMMF530PJP 30 Inch Multifunction Over-the-Range Smart Microwave Oven with 1.1 cu. ft. Capacity, 3-Speed 400 CFM Blower, 10 Power Levels, Steam Clean Mode, Air Fry Mode, Backlit Touch Controls, and Turntable-Free Design: Juniper

Buy More Save More
quick specs
Style: Over the Range
Fingerprint Resistant: Yes
Width: 30 Inch
Depth: 12 3/4 Inch
Height: 17 7/8 Inch
Cutout Width: 30 Inch
Cutout Depth: 12 3/4 Inch
Cutout Height: 18 Inch
WiFi: Yes
Capacity: 1.1 Cu. Ft.
Cooking Watts: 950 Watts
Convection: Yes
Quick Start Cooking: Yes
Sensor Cooking: Yes
Venting Type: Convertible
View more
$1,218.00
MSRP: $1,354.00
You save $136.00
OR
Buy more & save up to $4,000
See all eligible items
2
$300
3
$700
4
$1,000
5
$1,700
6
$2,800
7
$3,500
8
$4,000
Have questions? Chat with us!

Recommended Accessories & Add-ons

Product Information
Brand: KitchenAid
Model: KMMF530PJP
Appearance
Style: Over the Range
Color: Juniper
Fingerprint Resistant: Yes
Turntable: No
Dimensions
Width: 30 Inch
Depth: 12 3/4 Inch
Height: 17 7/8 Inch
Cutout Width: 30 Inch
Cutout Depth: 12 3/4 Inch
Cutout Height: 18 Inch
Smart
WiFi: Yes
Bluetooth: No
Alexa: Yes
Google Home: Yes
Remote Control: Yes
Remote Monitoring: Yes
Remote Diagnostics: Yes
App Integration: KitchenAid™ App
Smart Accessory Required: No
AI Technology: No
Capacity
Capacity: 1.1 Cu. Ft.
Cooking Watts: 950 Watts
Features
Convection: Yes
Broiler: Yes
Power Levels: 10
Kitchen Timer: Yes
Quick Start Cooking: Yes
Sensor Cooking: Yes
Speed Cook: Yes
Vent Fan Details
CFM: 400 CFM
Number Of Fan Speeds: 3
Venting Type: Convertible
Cooktop Lighting: Yes
Technical Details
ADA Compliant: No
Approved For Commercial Use: No
Approved For Outdoor Use: No
Amps: 15
Voltage: 120 Volts
Watts: 1,800 Watts
GTIN
UPC: 883049931265
Are you a Trade Pro? Join Now

Description

30 Inch Multifunction Over-the-Range Smart Microwave Oven with 1.1 cu. ft. Capacity
Free the countertop. This KitchenAid® Multifunction Over-the-Range Microwave Oven combines the versatility of an air fryer, toaster oven, convection oven, microwave, and ventilation hood, all in one space-saving appliance designed for flush installation within a standard 12 3/4" cutout.

Specifications

Product Overview
Microwave Type:
Over-the-Range
Cavity Finish:
Stainless
Door Release:
Touch to Open
Grill:
Yes
Grill Power:
1,700 W
Clock:
Yes
Work Surface Light:
LED
Sensor Cooking:
Yes
Display Color:
Full Color
Controls
Control Location:
Bottom
Control Type:
Electronic Touch
Convenience Cooking Controls:
Yes
Electronic Display Type:
LCD
Microwave Selections:
Add 30 Seconds, Air Fry, Auto Cook, Beverage, Convect, Cook Power, Cook Time, Cook/Start, Crisp, Defrost, Dinner Plate, End of Cycle Signal, Fresh Vegetable, Keep Warm, Languages - English/French, Off/Cancel, Pizza, Popcorn, Potato, Reheat, Soften/Melt
Number of Keypads:
32
Number of Power Levels:
10
Number of Sensor Control Keypads:
4
One Touch Cooking:
Yes
Smart Compatibility
Connectivity:
Amazon Alexa, Google Assistant
Smart Appliance:
Yes
Works With:
App, Remote Access, Voice Controlled, WiFi
Ventilation Details
CFM Motor Class:
400
Duct Direction:
Vertical or Horizontal
Duct Outlet Size:
3.25" W x 10" H
Duct Type:
Rectangular
Filters:
Charcoal Recirculating Filter, Dishwasher Safe Grease Filter
Vent Fan Location:
Back
Ventilation Type:
Updraft
Venting:
Exterior or Recirculating
Ventilation System
Night Light:
Yes
Blower Type:
Centrifugal
Fan Speed Indicator:
Yes
Electrical Requirements
Power Cord Included:
Yes
Dimensions & Weights
Width:
30"
Depth:
12-3/4"
Depth Closed Excluding Handles:
12-3/4"
Depth Closed Including Handles:
12-3/4"
Depth Excluding Doors:
12-3/4"
Depth With Door Open 90 Degree:
41-1/2"
Height:
17-7/8"
Interior Width:
18-1/8"
Interior Depth:
11"
Interior Height:
9-1/8"
Cutout Depth Max:
13"
Cutout Depth Min:
12-3/4"
Cutout Height Max:
18"
Net Weight:
74 1/10 lbs.
Gross Weight:
83 lbs.

Features

1.1 cu. Ft. Capacity
  • Provides enough interior space for mixing bowls, casserole dishes, and multiple food items. Accommodates a 9" x 13" casserole dish.
950-Watt Microwave Cooking Power
  • Provides microwave heating power for cooking, reheating, and defrosting food.
Air Fry Mode
  • Uses triple heating elements and a fan to circulate hot air around the included air fry basket, helping crisp and brown food with less oil than traditional deep frying.
Air Bake Mode
  • Uses triple heating elements and a fan for convection baking at temperatures up to 450°F.
Bake Mode
  • Uses dual heating elements to bake food at temperatures up to 450°F, offering an alternative to a countertop toaster oven.
Roast Mode
  • Uses dual heating elements and a fan to roast food at temperatures up to 450°F.
Broil Mode
  • Uses an upper grill heating element to broil food at temperatures up to 400°F.
Toast Mode
  • Provides a dedicated toasting function using the included toasting pan.
Multifunction Oven Modes
  • Combines baking, roasting, broiling, and toasting in one appliance, reducing the need for separate countertop cooking equipment.
Turntable-Free Design
  • Eliminates the traditional rotating glass turntable. A hidden motor circulates microwave energy throughout the cavity, maximizing usable cooking space.
Keep Warm Mode
  • Maintains low heat for up to 60 minutes to keep prepared food at serving temperature.
Microwave Cooking Modes
  • Provides cooking options including Cook, Reheat, Soften, Melt, and Defrost.
Sensor Cooking
  • Automatically adjusts cooking time and power based on detected moisture levels in food for more convenient cooking results.
Flush Built-In Design
  • Designed to provide a streamlined, built-in appearance when installed within standard 12¾-inch-deep cabinetry.
Backlit Touch Controls
  • Illuminates the electronic touch controls when in use and blends into the black glass surface when not in use.
Full-Color LCD Display
  • Displays cooking modes, temperatures, and cooking times for easier operation.
Tap-to-Open Door
  • Allows convenient access to the microwave cavity with a touch-operated door release.
Smart Appliance with Wi-Fi Connectivity
  • Connects to the KitchenAid app for compatible remote monitoring and control features.
Three-Speed 400 CFM Motor Class Ventilation System
  • Provides low, medium, and high fan speeds to help remove smoke, steam, and cooking odors from the kitchen.
Stainless Steel Covered Grease Filters
  • Helps capture grease and provides a finished appearance underneath the microwave.
Dual LED Cooktop Lighting
  • Illuminates the cooking surface below the microwave with two LED lights. Includes a night-light setting.
Steam Clean Mode
  • Uses steam to help loosen cooked-on food residue inside the microwave for easier cleaning.
Personalized Design
  • Allows the appliance's appearance to be coordinated with optional hardware accessories and KitchenAid's curated finish selections.
