GE JB480DYWW - 30 Inch Freestanding Electric Range with 4 Radiant Smoothtop Burners

Image Disclaimer

Authorized

Dealer

GE

JB480DYWW

30 Inch Freestanding Electric Range with 4 Radiant Smoothtop Burners, 5.0 cu. ft. Oven Capacity, Storage Drawer, Self-Clean Oven, Dual-Element Bake, Hot Surface Indicator, and ADA Compliant: White

Average rating of
1 review

Top Quality Store on Google

Only 2 left in stock

quick specs

Sabbath Mode: No

Cooktop: Smoothtop

Drawer: Storage

Width: 30 Inch

Depth: 29 Inch

Height: 47 Inch

Alexa: No

Google Home: No

Number of Burners: 4

Primary Oven Capacity: 5 Cu. Ft.

Hot Surface Indicator Light: Yes

Convection: No

Self-Cleaning: Yes

Steam Clean: No

Glide Rack(s): No

Temperature Probe: No

Warranty Terms: 1 year

Color: White

White

JB480DYWW

$1,339.00

^$1,339^.00

You Will Also Need:

Electric Cord Kit - 40 Amp, 4 ft.

+ $49.99

Have questions? Chat with us!

30 Inch Under Cabinet Range Hood

$169.00

1.7 cu. ft. Over-the-Range Microwave

$254.00

Product Information

Brand: GE

Model: JB480DYWW

Warranty Terms: 1 year

Appearance

Fuel Type: Electric

Style: Freestanding

Color: White

Cooktop: Smoothtop

Cooktop Control Type: Knobs

Oven Control Type: Knobs

Viewing Window: Yes

Double Oven: No

Drawer: Storage

Clock: No

Downdraft Venting: No

Dimensions

Width: 30 Inch

Depth: 29 Inch

Height: 47 Inch

Interior Width: 23 3/4 Inch

Interior Depth: 18 1/2 Inch

Interior Height: 19 Inch

Shabbos Compliance

Sabbath Mode: No

Smart

WiFi: No

Bluetooth: No

Alexa: No

Google Home: No

Remote Control: No

Remote Monitoring: No

Remote Diagnostics: No

Dash Replenishment: No

Smart Accessory Required: No

Capacity

Number of Burners: 4

Primary Oven Capacity: 5 Cu. Ft.

Burner

Power Burner: No

Burner 1 Output: 2000W

Burner 2 Output: 1500W

Burner 3 Output: 2000W

Burner 4 Output: 1500W

Electric Cooktop Features

Hot Surface Indicator Light: Yes

Power Boil: No

Oven Features

Digital Temperature Display: No

Timer: No

Delay Bake: No

Fast Preheat: No

No Preheat: No

Convection: No

Proof Mode: No

Self-Cleaning: Yes

Self-Cleaning Type: High Heat

Steam Clean: No

Racks: 2

Glide Rack(s): No

Temperature Probe: No

Broiler Element Location: Top

Broiler Pan Included: No

Interior Oven Light: Yes

Air Fry: No

Sous Vide: No

Steam Assist: No

Technical Details

ADA Compliant: Yes

Energy Star Rated: Yes

Oven Wattage: 2,585

LP Conversion: No

Amps: 40

Voltage: 240/208 Volts

GTIN

UPC: 84691970583

Description
Specifications
Features
Reviews

Description

30 Inch Freestanding Electric Range with 4 Radiant Smoothtop Burners
This GE electric range is ideal for any home, with 4-smoothtop burners for sauteing, boiling water, making soups, and gently simmering a sauce. The 5.0 cubic feet oven features a 4-pass bake element on the bottom and a 6-pass broil element on top. A removable full-width storage drawer neatly stores big trays and other cookware for quick access while saving cabinet space. The two oven racks can be adjusted to your preferred baking position. This electric range also has a dual-element bake, self-clean oven, black ceramic glass cooktop surface, and an interior oven light.

Specifications

General Specifications

Product Type:

Free-Standing Single Oven

Configuration:

Range with Storage Drawer

Textured Steel Side Panels:

Yes

Drawer Type:

Removable Full-Width Storage

Fuel Type:

Electric

Cooktop Features

Cooktop Burner Type:

Radiant Smoothtop

Cooktop Surface:

Black Ceramic Glass

Element - Right Front:

8" - 2,000W

Element - Left Front:

6" - 1,500W

Element - Left Rear:

8" - 2,000W

Element - Right Rear:

6" - 1,500W

Oven Features

Total Capacity:

5.0 cu. ft.

4-Pass Bake Element:

Yes

6-Pass Broil Element:

Yes

Interior Oven Light:

1 Incandescent Light

Oven Cleaning Type:

Self-Clean

Oven Rack Features:

2 Oven Racks, 6 Rack Positions

Auto Oven Shut-Off with Override:

Yes

Weights and Dimensions

Net Weight:

141 lb.

Cabinet Width:

30"

Oven Interior Dimensions (W x H x D):

23 3/4" x 19" x 18 1/2"

Overall Height:

47"

Overall Width:

30"

Overall Depth:

29"

Depth with Door Open:

46 3/4"

Depth Without Handle:

26 1/4"

Height to Cooking Surface:

36" - 36 1/2"

Power/Ratings

Electrical Requirements:

208/240V ; 60Hz ; 40A

Amp Rating at 208V:

Broiler Wattage:

3410W

Amp Rating at 240V:

KW Rating at 240V:

10.5

Bake Wattage:

2585W

KW Rating at 208V:

7.9

Warranty

Parts Warranty:

Limited 1-year Entire Appliance

Labor Warranty:

Limited 1-year Entire Appliance

Claims & Certifications

ADA Compliant:

Yes

Features

5.0 cu. ft. Oven Capacity

Enough room to cook an entire meal at once.

Storage Drawer

Large trays and other cookware can be conveniently stored for quick access.

Self-Clean Oven

Cleans the oven cavity without the need for scrubbing.

Dual-Element Bake

Upper and lower elements produce even heat and great results.

Front Controls

Easily-accessible controls make it simple to control the stovetop and oven.

2 Oven Racks

Feature a durable construction to help accommodate any size or type of cookware.

Other Features

4 Radiant Smoothtop Burners

Hot Surface Indicator Light

Large Oven Window

ADA Compliant

Reviews

Manuals & Guides

Specification Guide

Owners Guide

GE JB480DYWW 30 Inch Freestanding Electric Range with 4 Radiant Smoothtop Burners, 5.0 cu. ft. Oven Capacity, Storage Drawer, Self-Clean Oven, Dual-Element Bake, Hot Surface Indicator, and ADA Compliant: White
