Description
20 Inch Under Cabinet Convertible Range Hood with 270 CFM Internal Blower
Summit's selection of specialty appliances includes accessible range hoods specially designed to be installed in compliance with Sections 308 and 309 of the ADA Guidelines. Model HC20SSADA is a 20" wide range hood ideal for apartments, senior living kitchens, hotel suites, and other smaller spaces. It comes in a stainless steel finish with a horizontal grain constructed from 21 gauge galvanized steel for lasting durability. It has a remote terminal block and wall switch cover to allow the controls to be installed separately from the hood and at a lower, accessible height by ADA guidelines. The fan can be set at a high or low setting to best meet your ventilation needs. This unit can operate at 270 CFM for thorough ventilation. Airflow is directed upwards at a slight angle, ensuring smoke and odors won't blow towards the home chef.
This hood ships for ductless/recirculating ventilation (where no exhaust connection to the outside is available) but is convertible for horizontal or vertical ducted ventilation (3 1/4" x 10" rectangular ducting or 7" round, transition required). It includes a combination aluminum mesh/charcoal filter to absorb grease, smoke, and odors. This unit accepts a standard light bulb (not included). Filter and lens cover snap in place, with no tools required to change out as needed. In addition to this ADA-compliant range hood, Summit manufactures this series in additional colors, shell hoods, and wall-mounted European hoods. Browse the full Summit product line to explore your options.
Note: This hood does not include a power cord and is designed to be hard-wired by a licensed professional.
Specifications
Range Hood
Installation:
Under Cabinet
Maximum Air Movement:
270 CFM
Duct Shape:
3 1/4" x 10" Rectangular or 7" Round with Transition
Electrical Specifications
Voltage/Frequency:
115 V AC/60 Hz
Dimensions & Weight
Height of Cabinet:
5 1/2"
Shipping Weight:
16.5 lbs.
Warranty
Parts & Labor Warranty:
1 Year
Claims & Certifications
US Electrical Safety:
ETL
Canadian Electrical Safety:
ETL-C
Features
270 CFM Internal Blower
- Can operate at 270 CFM to ensure thorough ventilation of your cooking surface
Two Speed Fan
- High and low setting to allow proper ventilation of your kitchen as needed
Combination Charcoal/Aluminum Mesh Filter
- Aluminum filter includes charcoal filler to absorb smoke, grease, and odors for a cleaner kitchen experience
Rocker Switch Controls
- Front-located on/off and high/low switches make it easy to manage the light and fan
Angled Airflow
- Vents are set at a slight upwards angle, ensuring smoke and odors won't be directed towards the user
Versatile Top or Rear Exhaust
- Can be connected to 3 1/4" x 10" vertical or horizontal exterior venting or 7" round vertical (transition required for both)
Accepts A Standard Bulb
- Designed to hold a standard incandescent light bulb with easy installation and no tools required
Removable Filter
- Snap-in design allows you to easily remove the filter for fast replacing as needed
Durable 21 Gauge Steel Construction
- Stainless steel exterior with a body that's 53% heavier gauge than most of the industry's under cabinet hoods
Convertible Design
- Can be used for ducted venting to the outside or recirculating ventilation where no external venting is possible
Easy Conversion
- Ships pre-set for recirculating mode but can be converted in a few simple steps
Professional Installation
- Designed to be hard-wired by a licensed professional
ADA Compliant Design
- Hood is wired to run off a wall switch for improved accessibility, with a remote terminal block included
Made in North America
