Capacity
Fresh Food Capacity:
18.3 cu. ft.
Freezer Capacity:
9.6 cu. ft.
Total Capacity:
27.9 cu. ft.
Refrigerator Specifications
Fresh Food Cabinet Shelves:
1 Fixed Glass Shelf, 3 Adjustable Glass Shelves
Fresh Food Door Bins:
2 Extra Large Gallon Depth, 3 Standard Depth
Total Fresh Food Door Bins:
5
Fresh Food Cabinet Drawers:
2 Total Fresh Food Drawers
Bins Have:
2 Adjustability Points
Freezer Specifications
Freezer Cabinet Shelves:
1 Fixed Glass Shelf, 4 Adjustable Glass Shelves
Freezer Cabinet Drawers:
1 Total Freezer Drawer
Freezer Door Bins:
2 Standard Depth
Flush Mount LED Lighting:
Yes
Icemaker & Dispenser
In-Door Icemaker:
Factory-Installed, Advanced Water Filtration
Ice Bucket Capacity:
Up to 7 lbs.
Dispenser Features:
Crushed Ice, Cubed Ice, Water, Extra Tall 11-Inch Dispenser, LED Dispenser Light
Water Filtration:
Advanced Water Filtration Certified, (XWFE Filter)
Features
Temperature Management:
MultiVent Cooling, Turbo Cool Option, Turbo Freeze Option
Control Type:
Internal Controls
Control Location:
Right Wall Of The Fresh Food Section
Temperature Display:
Internal Digital
Lighting:
Flush Mount LED Light Bars
Performance Features:
Never Clean Condenser
Filter Location:
Lower Fresh Food
Cord Length:
6 Foot Power Cord
Leveling System:
2 Point Front Adjustable
WiFi Connect:
Optional (Requires part no. PBX23W00Y1)
Control Lock Capability:
Yes
Control Features:
Filter Expired, Freezer Temperature, Fridge Temperature, Icemaker, Leak Detected, Replace Filter, Turbo Cool (Hold Fridge for 3 Seconds), Turbo Freeze (Hold Freezer for 3 Seconds)
Appearance
Installation:
Free-Standing
Color Appearance:
Fingerprint Resistant Stainless
Textured Steel Case:
Gray
Dispenser Color:
Color-matched
Exterior Design:
Contoured Doors
Handle Color:
Stainless Steel
Hidden Door Hinge(s):
Yes
Leveling System:
2 Point Front Adjustable
Power / Ratings
Electrical Requirements:
115V
Volts/Hertz/Amps:
115v; 60Hz; 15A
Weights & Dimensions
Approximate Shipping Weight:
360 lbs.
Width with Door Open 90 Degrees Incl. Handle:
43 1/8"
Overall Depth with Handle:
36"
Depth Without Handle:
34"
Depth with Door Open 90°:
51 1/4"
Height to Top of Hinge:
69 15/16"
Height to Top of Case:
68 15/16"
Case Depth Without Door:
29 7/16"
Clearance to Adjacent Wall with Freezer Door Open 90°:
3 11/16"
Clearance to Adjacent Wall with Fresh Food Door Open 90°:
3 3/4"
Side Air Clearances:
1/8"
Warranty
Labor Warranty:
Limited 1-year Entire Appliance
Parts Warranty:
Limited 1-year Entire Appliance
Warranty Notes:
See Written Warranty For Full Details
Certifications
Claims & Certifications:
California Prop 65, CEC Regulated, California AB-100 Compliant, Lead Leaching NSF61/AB100 Compliant, Lead Leaching NSF61/AB100 Third Party Certified, Lead Leaching NSF61/AB100 Applicable
OU Certified:
OU/CRC Enhanced Shabbos Mode, when used with Shabbos Keeper, Sold Separately
