Overview
Style:
Built-In Top Control
Number of Place Settings:
16
Control Type:
Top Controls, Fully Integrated Inlaid Electronic Buttons, 6 Touchpads
Dishwasher Control Features:
3 Digit Countdown Display with 1 "Clean" light / 1 "Sanitized" light Cycle Progress Indicators, Last Cycle Memory, Audible End-of-Cycle Signal
Dispenser:
Detergent, Rinse Aid
Wash Arms:
Upper, Middle, Lower
Water Filtration System:
100% Filtration with Piranha Hard Food Disposer and Removable Filter
Tub and Door Liner:
Hybrid Stainless Steel Interior
Door Liner:
Clean Design with Stainless Steel
Exterior Style:
Traditional
Leveling System:
4 Leveling Legs
Features
Active Flood Protection:
Active Flood Protect
Dishwasher Drying Features:
Dry Boost™, Calrod Heater
Wash System Features:
Piranha™ Hard Food Disposer with Removable Filter, Automatic Temperature Control, Automatic HotStart, Fill Level Pressure Sensor, Active Flood Protect, Bottle Jets
WiFi Connect:
Optional (Requires part no. PBX23W00Y1)
Cycles
Dishwasher Cycles:
AutoSense, Heavy Wash, Normal Wash, 1 Hour Wash
Options
Dishwasher Options:
Dry Boost™ (High), Dry Boost™ (Normal), Wash TempBoost, Steam + Sani (Certified to NSF Standard 184), Start/Reset, Lock Controls, Delay Start 1-12 Hr. with Countdown, Steam PreWash, Sabbath Mode
Rack Features
Cutlery Tray:
3rd Rack Included
Rack Features:
1 Piece Silverware Basket with 3 Cell Covers, Ball-Tipped Tines
Upper Rack:
Removable, Adjustable, Bottle Jets
Appearance
Color Appearance:
Fingerprint Resistant Stainless
Door Appearance:
Full-Length Flat Door
Handle Color:
Fingerprint Resistant Stainless
Installation:
Side Installation or Top Installation Included, Built-Up Floor Capable
Economical / Quiet
Accessories
Optional Accessories:
Optional Cord Kit (GPFCORD), Optional 12' Drain Hose Kit (WD24X10065)
Power / Ratings
Calrod Heater Watts:
800/500
Electrical Requirements:
120V ; 60Hz ; 7.1A
Energy Consumption (kWh/year):
240
Power Connection:
Optional cord kit (GPFCORD - WX09X70910, WX09X70911)
Weights & Dimensions
Approximate Shipping Weight:
75 lbs.
Depth with Door Open:
27 1/2"
Height w/ Legs Retracted - Minimum Height:
33 3/8"
Height w/Legs Extended - Maximum Height:
34 5/8"
Warranty
Labor Warranty:
Limited 1-year Entire Appliance
Parts Warranty:
Limited 1-year Entire Appliance
Certifications
Claims & Certifications:
ENERGY STAR® Qualified, NSF Certified, MADE IN AMERICA: 70 to 90% U.S. Content, California Prop 65, CEC Regulated
