Cooking Controls
Cooking Controls Function
Program Fahrenheit or Celsius:
Yes
Silent Control Panel:
Yes
Cooktop
Cooking Surface Type:
Smooth
Element On Indicator Light:
Yes
Hot-Surface Indicator Light:
Yes
Drawer
Drawer Handle Style:
Integrated
Display
Display Interface Color:
White
Display Type:
Capacitive Touch
Electrical Specifications
Minimum Circuit Required:
40 Amps
General Specifications
Performance Certifications and Approvals
ENERGY STAR Certified:
Yes
Oven
Bake Element Type:
Hidden
Broil Element:
4000 Watts
Convection Element:
3800 Watts
Number of Convection Fans:
1
Number of Rack Positions:
6
Oven Interior Color:
Midnight Black
Rack Position Type:
Embossed
Window Type:
Extra Large Visual
Cooktop Performance
Right Front Element Burner Size:
8 3/10"
Right Rear Element Burner Size:
5 1/2"
Left Front Element Burner Size:
7"
Left Rear Element Burner Siz:
e 7"
Right Front Element Burner:
2,300 / 3,600 Watts (Boost)
Right Rear Element Burner:
1,400 / 2,500 Watts (Boost)
Left Front Element Burner:
1,800 / 2,800 Watts (Boost)
Left Rear Element Burner:
1,800 / 2,800 Watts (Boost)
Controls
Dimensions and Volume
Depth With Door 90° Open:
47 5/16"
Depth With Handle:
28 1/2"
Oven Interior Height:
18 1/8"
Oven Interior Width:
25 3/16"
Oven Interior Depth:
19 7/8"
Oven Capacity:
5.3 Cu. Ft.
Installation
Adjustable Leveling Legs:
Yes
Certifications and Approvals
Star-K Certification:
Yes
Safety Certifications and Approvals
