Additional Specs
Finish:
Professional Design - Stainless Steel
Cooking Surface:
Black Enameled
Gas Cooktop Features
Electric Flame Ignition and Re-ignition:
Yes
Dual Crown Burners (Brass):
Yes
Heavy Duty Cast Iron Grates:
2 + 1 trilaminate griddle
Cooking Zones (Natural Gas)
Front Left (power max):
20000 (BTU/h) - 5850W
Front Left (power min):
750 (BTU/h) - 220W
Rear Left (power max):
18000 (BTU/h) - 5300W
Rear Left (power min):
750 (BTU/h) - 220W
Middle Griddle (power max):
11500 (BTU/h) - 3370W
Middle Griddle (power min):
2000 (BTU/h) - 590W
Front Right (power max):
20000 (BTU/h) - 5850W
Front Right (power min):
750 (BTU/h) - 220W
Rear Right (power max):
18000 (BTU/h) - 5300W
Rear Right (power min):
750 (BTU/h) - 220W
Cooking Zones (Liquid Propane)
Front Left (power max):
15000 (BTU/h) - 4400W
Front Left (power min):
750 (BTU/h) - 220W
Rear Left (power max):
15000 (BTU/h) - 4400W
Rear Left (power min):
750 (BTU/h) - 220W
Middle Griddle (power max):
11500 (BTU/h) - 3370W
Middle Griddle (power min):
2000 (BTU/h) - 590W
Front Right (power max):
15000 (BTU/h) - 4400W
Front Right (power min):
750 (BTU/h) - 220W
Rear Right (power max):
15000 (BTU/h) - 4400W
Rear Right (power min):
750 (BTU/h) - 220W
Oven Features
Oven Type:
Multifunction 2 Fans
Temperature Regulation:
Electronic probe with glow wire
Oven Functions:
Pizza Mode, Bake, Dehydrate, Broil (Nova Broiler), Convection Bake
Electric Oven Features:
Hot Surface Ignition, Flame Out Sensing, Gas Safety Devices, Timed Cooking Functions, Sabbath Mode, Clock Format 12-24, Pizza Function, L.P. Conversion Kit
Oven Glass Window:
Deep Embossed Window
Door Cooling System:
4 Pane Heat Resistant Glass
Door Hinges / Soft Closing:
Heavy Duty Steady Tilt
Handle Style:
Stainless Steel Tube d 30 mm, Metal terminals
Net Capacity (cu. ft.):
5.7
Cavity Enameling Colour:
Black
Rack Positions / Oven Lights:
6 / 3x20W Halogen
Control Panel
Control type:
EKOTIME - Electronic Control
Temperature Display:
°F (5° increments)
Commands:
8 Heavy Duty Knobs
Broil Burner
Power Natural Gas:
18000 (BTU/h) - 5300W
Power Propane:
17000 (BTU/h) - 5000W
Bake Burner
Power Natural Gas:
21500 (BTU/h) - 6300W
Power Propane:
21500 (BTU/h) - 6300W
Enameled Grill set (basin + anti-splash):
1
Telescopic chromed rack:
1
Dimensions & Weights
Overall Height:
35 3/8" to 37 - 1/4"
Power / Ratings (208/240 V, 60 HZ)
kW / Amps rating at 120V, 60Hz:
1000 W - 8,3A
Cable + Plug | Cable length:
Nema 5 -15P | 51"
