Details
Heating Technology:
EGO Induction B4 (UL certified)
Glass Type:
Glass Ceramic
Control Features
Pot Detection System:
Standard
Failure Codes Indication:
Yes
Slide Touch Control for Power Setting:
Yes
Digital Display for Power Level Indication (7 segments):
Yes
Led bar for power level indication:
Yes
Melting Func. 113°F / 45°C (inside the pot 108°F / 42°C) (MELT. led cap):
Yes
Booster/Fast Boil Function for Each Zone:
Yes
Heat Up Time Automatic Function for Each Zone:
Yes
Residual Heat Indication for Each Zone (HOT led caps):
Yes
Minute Minder Functions for Each Zone + One General (Led Indicator):
1+4
Key Lock (Led Indicator):
Yes
Pause/Recall (Led Indicator):
Yes
General ON/OFF Key (Led Indicator):
Yes
Dedicated ON/OFF Key for Each Zone:
Yes
Burner Output
Burner 1:
2300W - 3000W (Front Right)
Burner 2:
1400W - 1850W (Front Left)
Burner 3:
2300W - 3000W (Rear Left)
Burner 4:
1400W - 1850W (Rear Right)
Dimensions & Weight
Overall Height (without Conduit):
2 7/8"
Cutout Width (min - max):
min. 22 5/8" - max 22 13/16"
Cutout Depth (min - max):
min. 19 1/4" - max 19 9/16"
Box Height:
2 3/4" + conduit 1 1/8"
Approx Ship Weight:
33 lbs
Power / Ratings (208/240 V, 60 HZ)
KW/Amps Rating at 240V, 60Hz:
7.20kW - 30Amps
KW/Amps Rating at 208V, 60Hz:
6.30kW - 30Amps
