Description
How to Choose a Room Air Conditioner
Compared to large capacity central units, room air conditioners have several advantages. The initial cost of a room air conditioning unit is significantly lower than the cost of central air. Because room air conditioners are designed for cooling small spaces, operating costs are reduced. And, room air conditioners can provide personalized temperature and humidity controls that central systems cannot.
Calculating Cooling Capacity
Cooling capacity is the critical factor in properly selecting a room air conditioner. Cooling capacity is measured in British Thermal Units (BTUs) and typical models will range in capacity from 5,000 BTUs to 28,500 BTUs.
Choosing an undersized unit will overwork the unit and it will not cool properly. Choosing an oversized unit will cost more to buy and operate and it will not dehumidify properly.
We can help you to calculate capacity. Be prepared to provide specific information on:
- Room Dimensions
- A simple floor plan to show the location of doors and north-facing windows
- The number of people it will serve
- Sources of heat such as lamps, TV and appliances
- An explanation of what's above the intended room
- Your insulation provisions
Cooling Capacity by Room Size
Measure the length and width of the area to be cooled. Multiply the length by the width to determine square footage or square meters. When cooling rooms with uninsulated ceilings, great rooms, or southern or western sun exposures - step up to the next BTU size.
| Room Size | BTU |
|
| Sq. Ft. | Sq. m | |
| 150 | 14 | up to 5,000 |
| 165 | 15 | 5,200 |
| 216 | 20 | 6,000 |
| 350 | 33 | 8,000 |
| 425 | 39 | 9,000 |
| 500 | 46 | 10,000 |
| 640 | 60 | 14,000 |
| 900 | 84 | 15,100 |
| 1,110 | 103 | 18,000 |
| 1,170 | 109 | 18,500 |
| 1,435 | 133 | 22,000 |
| 1,672 | 154 | 25,000 |
| 1,960 | 182 | 28,500 |
Energy Info
This air conditioner has an Energy Efficiency Rating of 11.2 and has an estimated yearly operating cost of $44.93.
Your operating costs will depend on your utility rates and use. The estimated yearly operating cost is based on the 2011 national average cost of $.1109 cents per kWh for electricity and an estimated number of operating hours of 750 hours.
For more information, visit www.ftc.gov/appliances.
Specifications
Performance
Dehumidification:
1.5 Pints/Hr.
Air Flow Volume CFM High:
200 CFM
Air Flow Volume CFM Med:
175 CFM
Air Flow Volume CFM Low:
160 CFM
Electrical
Voltage Frequency:
115 V - 60 Hz
Min Power Cord Length:
6 Ft.
Electrical Receptacle:
125V/15A
Features
Area To Cool:
151 - 250 Sq. Ft.
On/Off Timer (24 Hour):
Yes
Infrared Remote Control:
Yes
Fahrenheit To Celsius Function:
Yes
Easy Install Window Curtain:
Yes
Exterior Appearance
Agency Approvals
Performance Certification:
AHAM, EEV
Safety Approvals:
UL, CUL
Dimensions and Weights
Window Width:
26 1/11" Min. - 39 1/4" Max.
Window Height:
13 3/8" Min.
Shipping Weight:
62.8 Lbs.
Features
3 Cool/Fan Speeds Plus Auto Cool
- Multiple speeds for personalized comfort.
- Auto Cool adjusts fan speed depending on cooling need.
Cool, Fan, Energy Save, Dehumidify
- Cool the room, circulate the air, save energy when cooling or reduce humidity all in one unit.
Cool and Fan Modes
- Cool the room or circulate the air in one unit.
24 Hour Timer + Sleep Mode
- Program to turn on or off anytime in a 24 hour period.
- Sleep mode auto-adjusts temperature for overnight comfort.
MagnaClik Remote with Braille
- Store the remote on the unit so it is never misplaced.
- Braille for the visually impaired.
4 Way Air Direction
- Direct the air flow to where you want it.
Quick Install Window Kit
- The window kit assembles to the unit in minutes.
Easy Access Washable Filter
- Filter removes quickly and rinses clean for easy maintenance.
Digital Timer and Temperature Display
- Alternate between time and temperature display.
