Description
24 Inch Fully Integrated Built-In Panel Ready Dishwasher with 15 Place Setting Capacity
The Smeg DW8220 is where elegant design meets top-tier performance. Fully integrated and panel-ready, it disappears seamlessly into your kitchen, creating a clean, cohesive look. Inside, it offers a generous 15-place setting capacity—perfect for busy households or frequent entertainers. Advanced features like Smeg’s Orbital Wash System deliver a powerful, quiet clean, while 10 versatile wash cycles handle everything from delicate glassware to heavily soiled pots. With flexible rack configurations, energy-efficient natural drying, and a sleek stainless steel tub, the DW8220 is built for both beauty and performance. Quiet, smart, and efficient, it transforms the way you do dishes—effortlessly.
Specifications
General Specifications
Installation Type:
Fully-integrated built-in
Number of Place Settings:
15
Tub Material:
Stainless steel
Concealed Heating Element:
Yes
Flood Protection System:
Single Aquastop
Water Softener:
With electronic setting
Max Water Hardness:
100°fH; 58°dH
Adjustable Feet:
2 3/4", adjustable from 32 1/4" to 35"
Plinth Height:
Min 50 mm (2") / Max 215 mm (8.5")
Hinges:
Self-balancing, Sliding, FlexiFit
Min. and Max. Frontal Panel Weight:
4.4 - 24.3 lbs
Technical Features
Washing System:
Orbital Wash System
Drying System:
Natural condenser drying with Dry Assist+ automatic door opening system at the end of the cycle
Turbidity Sensor (Aquatest):
Yes
Display Type:
LED display (3 digits)
Program Progress Indicator:
Yes
End-of-Cycle Indicator:
Acoustic signal
Rinse Aid Indicator:
Light
Electrical Connection
Connection Type:
Single-phase
Power Supply Cable Length:
140"
Dimensions & Weights
Packaged height:
35 1/16"
Features
15 Place Setting Capacity
- Spacious design to clean up to 15 standard place settings in one cycle, perfect for families and gatherings.
10 Wash Cycles
- Offers a variety of programs tailored for different cleaning needs, from delicate glassware to heavy pots.
Flexible Third Rack
- Extra loading space for cutlery and small utensils, keeping them secure and maximizing dishwasher capacity.
Orbital Wash System
- Ensures thorough cleaning with multi-directional spray arms that reach every corner of the dishwasher.
Flexifit Hinge System
- Allows the dishwasher door to fit seamlessly into different kitchen layouts for easy installation.
Dry Assist System
- Improves drying efficiency by slightly opening the door at the cycle end to release steam and prevent moisture buildup.
Delay Timer
- Enables you to schedule the wash cycle to start at a convenient time, saving energy during off-peak hours.
44 dBA Noise Level
- Quiet operation ensures the dishwasher runs unobtrusively, ideal for open-plan living spaces.
Inverter Technology
- Provides efficient and reliable motor performance, reducing energy consumption and noise.
Acquastop
- Safety feature that automatically stops water flow in case of leaks, protecting your home from flooding.
FlexiZone
- Allows washing smaller loads in either the upper or lower rack to save water and energy.
Auto 45°- 65°
- Automatically adjusts water temperature between 45° and 65° for optimal cleaning based on soil levels.
Ultraclean
- Intensive cycle for heavily soiled pots and pans, delivering powerful cleaning performance.
Delicate
- Gentle cycle designed for fragile glassware and fine china to prevent damage.
Rapid 27 Mins
- Quick wash cycle that cleans lightly soiled dishes in just 27 minutes, perfect for fast turnaround.
