Description
18 Inch Fully Integrated Dishwasher with 8 Place Settings
Summit's European dishwashers offer efficiency for the home with ultra-quiet operation. Model DW185SSADA is an 18" wide dishwasher sized 32.25" high for an easy fit under lower ADA Compliant counters. Leveling legs allow you to raise the height to 34" and include an extra kickplate to cover the front for a cleaner look and to help prevent dirt from getting under the unit. This model features a stainless steel door with a curved brushed stainless steel handle for a modern kitchen look, with top-mounted controls for a more seamless appearance under your counters. The DW185SSADA features stainless steel construction for durability. Advanced sound absorption ensures a quiet performance at just 47 dB. With eight versatile wash programs, this unit handles everything from tough stains with the "Intensive Plus" setting to delicate care for your most fragile items. Five auxiliary functions let you customize the wash and dry settings with sanitize, extra fast, extra dry, high temperature, and half load for added efficiency. The upper slide-out rack can be set in two positions, allowing you to adjust the setup if washing particularly tall items. Side flaps can stack smaller cups, keep glasses in place, or hold long utensils. The lower rack includes two fold-down tines that let you better accommodate oversized pots as needed. A removable cutlery basket makes it easy to load and unload silverware. The control panel features easy touch buttons and a digital display for intuitive operation. Two spray arms ensure thorough cleaning of every load. Additional features include a pause function, a 19-hour delay start option, and indicators for rinse aid, water cutoff, and overflow. In addition to this dishwasher, Summit offers a fully integrated version that accepts custom panels (model DW186NTADA) and additional styles with front controls.
Specifications
Overview
Fold Down Tines:
Yes, Lower Rack
Interior Finish:
Stainless Steel
Energy Usage/Year:
250 kWh/year
Dishwasher Features
Number of Cycles:
8 (Regular, Auto, Intensive, Intensive Plus, Daily, Delicate, Super, & Rinse)
Number of Options:
5 (Sanitize, Extra Fast, Extra Dry, Hi-Temp, and Half Load)
Automatic Detergent Detection:
Yes
Electrical Specifications
Voltage/Frequency:
115 V AC/60 Hz
Dimensions & Weight
Height of Cabinet:
32 1/4"
Depth with Handle:
24 1/4"
Depth with door at 90°:
45 1/2"
Cutout Height:
32 7/16 - 34 7/16"
Warranty
Parts & Labor Warranty:
1 Year
Claims & Certifications
Canadian Electrical Safety:
ULC
ENERGY STAR Certified:
Yes
Features
8 Place Settings
- Slim fit with full dishwashing capability for a great addition to any small kitchen
47 dBa
- Advanced sound absorbing construction operates at 47 dB
8 Wash Cycles
- Settings include Regular, Auto, Intensive, Intensive Plus, Daily, Delicate, Super, & Rinse
5 Auxiliary Functions
- Combine additional functions with your wash programs, including Sanitize, Extra Fast, Extra Dry, Hi-Temp, and Half Load
Nylon Coated Wire Racks
- Two easy-gliding racks for easy loading and long-lasting durability
Adjustable Top Rack
- The upper rack can be repositioned to help accommodate taller items
Side Rack Arms
- Top rack includes side pieces that help to keep tall glasses safely in place, or alternatively, allow you to maximize capacity by stacking smaller cups or holding longer items
Half Load Function
- Can be combined with any wash program to operate more efficiently for smaller loads of dishes
Delay Start Option
- Allows you to program a wash cycle for up to 19 hours in advance
Sanitize Setting
- Increases the water temperature in the final rinse for a cleaner wash
Water Cutoff Warning
- Washing will stop if the machine detects an issue with the water supply or inlet tap
Overflow Warning
- Alert will flash if the dishwasher is taking in too much water or sensing a leak
Automatic Detergent Detection
- Unit will self-adjust to the detergent type for optimum performance
Indicator Lights
- Display screen will show when softening rinse aid needs to be adjusted
Touch Controls
- Intuitive button controls with a digital display to ensure you select the proper cycle
Two Spray Arms
- Improved design to ensure both racks are properly cleaned
Fold-Down Tines
- Lower rack includes two tines that can be folded down to make room for larger items, or raised to hold dishes in place
Detergent Dispenser
- Conveniently located inside towards the top of the door, with a push button release for easy loading
Removable Cutlery Basket
- Convenient basket makes it easy to arrange your silverware, and is also removable to open up more space if washing larger pots or pans
Removable Filter
- If food particles build up in the bottom filter, it can easily be removed and emptied as needed
Top Control Panel
- Touch controls are located on the top of the door, providing a cleaner look to better integrate into your kitchen
Adjustable Height
- Includes three leveling legs that let you raise the unit to a standard 34" counter height, with an taller kickplate included to cover extra space
ADA Compliant
- 32 1/4" high to fit under lower counters following ADA guidelines
ENERGY STAR Certified
- Uses less energy and water than national standards require to ensure more efficiency and lower utility bills
Additional Features
- Pro Style Brushed Stainless Steel Curved Handle
