Description
30 Inch Wall Mount Range Hood with 3 Speed/512 CFM Blower
The Miele DAP 1727 is a 30-inch wall-mounted ventilation hood crafted from stainless steel, offering a sleek and modern design that complements a wide range of kitchen styles. It is suitable for both vented and recirculating installations, giving flexibility based on your kitchen layout.
This model features EasySwitch electronic controls with three power levels and an additional Booster setting for intensive extraction. It includes two 3W LED lights that deliver a light intensity of 330 lux and a warm 3000 K color temperature, effectively illuminating your cooktop while being energy-efficient.
To ensure clean operation, the DAP 1727 includes two 10-ply stainless steel grease filters that are dishwasher-safe for easy maintenance. The interior is designed with Miele’s CleanCover, which is a sealed and smooth surface that prevents contact with electrical components, enhancing both hygiene and safety.
For added convenience and protection, the unit includes a safety shut-off function that powers down the hood after 10 hours of continuous operation. Overall, the DAP 1727 combines high performance, user-friendly controls, and premium design in a compact 30-inch format, making it a strong choice for modern kitchen ventilation.
Specifications
Construction Type and Design
Appliance color:
Stainless steel
Design
Wall ventilation hood:
Yes
Operating Modes
Recirculated mode:
Can be retrofitted
Recirculation conversion kit (order separately):
DUW 20
User Convenience
Power levels (number excl. Intensive):
3
Programmable Intensive switch-off:
Yes
Cleaning Convenience
Easy-to-clean canopy interior – CleanCover:
Yes
Filter System
Number of dishwasher-safe stainless steel grease filters (10-ply):
2
Lighting
Light intensity in Lx:
330 lx
Color temperature in K:
3000 Kelvin
Blower
Safety
Technical Data
Overall hood height for vented mode and external:
27" – 39 9/16"
Overall height for recirculation mode ventilation hoods:
32 1/16" – 44 11/16"
Overall min. height for vented and external:
27"
Overall max. height for vented and external:
39 9/16"
Overall min. height for recirculation:
32 1/16"
Overall max. height for recirculation:
44 11/16"
Length of electrical wire in ft:
4
Standard plug fitted:
Yes
Minimum height above electric cooktops:
24"
Minimum safety distance above gas cooktops (max. 12.6 kW total power, burner ≤ 4.5 kW)in mm:
26
Total connected load in kW:
0.35
Installation Note
Vent connection at top:
Yes
Vent connection at the top and rear:
Yes
Diameter of vent connection:
6"
Standard Accessories
Features
3 Speed/512 CFM Blower
- The hood features a dual-action blower with three standard speed settings, delivering up to 512 CFM (cubic feet per minute) of air throughput, ensuring efficient removal of cooking odors and grease.
EasySwitch Electronic Controls
- User-friendly EasySwitch electronic controls allow for intuitive operation, enabling you to adjust fan speeds and lighting with ease.
LED Lighting
- Equipped with two energy-efficient 3W LED lights, providing a light intensity of 330 lux and a warm color temperature of 3000 K, the hood ensures optimal illumination of your cooking area.
10-Ply Stainless Steel Grease Filters
- The hood includes two 10-layer stainless steel grease filters that effectively capture grease and are dishwasher-safe for easy cleaning.
Automatic Shut-Off
- For safety and energy conservation, the hood features an automatic shut-off function that turns off the unit after 10 hours of continuous operation.
Booster Level
- An intensive Booster level provides temporary increased airflow to handle heavy smoke or strong odors during high-heat cooking.
Vented or Recirculating Options
- The DAP 1727 is designed for flexibility, allowing for both vented (ducted) and recirculating (non-ducted) installations, with a recirculation conversion kit available separately.
Miele CleanCover
- The hood's interior features Miele's CleanCover, a sealed, smooth surface that prevents contact with electrical components, enhancing safety and simplifying cleaning.
