Description
46 Inch Stella Island Mount Smart Range Hood with 3-Speed/474 CFM Blower
The Miele DAC 2247 is a ceiling-mounted extractor designed for installation above an island cooktop. It features a sleek stainless steel design and provides powerful ventilation while maintaining a modern aesthetic. It includes Con@ctivity 3.0, which allows for smart connectivity and automatic fan adjustment. The LED lighting ensures bright and energy-efficient illumination. It supports both vented and recirculating installation modes, offering flexibility for different kitchen setups. The unit is designed for quiet operation, minimizing noise while maintaining high performance.
Specifications
Design
Operating Modes
Recirculated mode:
Can be retrofitted
Active charcoal filter (order separately):
DKF 35-P
User Convenience
Delayed shutdown for 5 or 15 minutes:
Yes
Grease filter saturation indicator:
Yes
Active charcoal filter saturation indicator:
Yes
Efficiency and Sustainability
Cleaning Convenience
Easy-clean CleanCover liner:
Yes
Filter system
Stainless steel grease filters:
4
Lighting
Light intensity in Lx:
450 lx
Color temperature in K:
3500 Kelvin
Blower
Exhaust Air
Air throughput in Booster (cfm):
474
Sound power in Booster (dBA):
70
Recirculation
Air throughput in Booster (cfm):
283
Sound power Booster (dBA):
69
Safety
Technical Data
Canopy dimensions (W x H x D):
45 7/8" x 11 5/8" x 19 11/16"
Min. height above electric cooktop:
24 1/8"
Min. clearance above gas cooktops:
26"
Total connected load in kW:
0.19
Installation Note
Vent connection on side:
Yes
Features
3-Speed/474 CFM Blower
- The hood features a powerful blower with three standard speed settings, delivering up to 474 CFM (cubic feet per minute) of air throughput, ensuring efficient removal of cooking odors and grease.
EasySwitch Electronic Controls
- User-friendly EasySwitch electronic controls allow for intuitive operation, enabling you to adjust fan speeds and lighting with ease.
LED Lighting
- Equipped with energy-efficient LED lights, the hood provides optimal illumination of your cooking area, enhancing visibility and ambiance.
10-Ply Stainless Steel Grease Filters
- The hood includes 10-layer stainless steel grease filters that effectively capture grease and are dishwasher-safe for easy cleaning.
Miele@home
- This smart home integration allows you to monitor and control your hood remotely via the Miele app, offering convenience and flexibility in managing your kitchen environment.
Automatic Function Con@ctivity
- The Con@ctivity feature enables the hood to communicate with compatible Miele cooktops, automatically adjusting the fan speed based on your cooking activity for optimal ventilation.
Remote Control Included
- A remote control is provided, allowing you to operate the hood's functions from a distance, adding convenience to your cooking experience.
1 Booster Level
- An intensive Booster level provides temporary increased airflow to handle heavy smoke or strong odors during high-heat cooking.
Programmable Intensive Switch-Off
- This feature allows you to set a timer for the intensive level, ensuring the hood returns to a lower setting after a specified period, conserving energy.
Delayed Shutdown
- The delayed shutdown function enables the hood to continue operating for a set time after cooking, effectively removing residual odors and heat.
Grease Filter Saturation Indicator
- An indicator alerts you when the grease filters require cleaning, ensuring the hood maintains optimal performance.
Active Charcoal Filter Saturation Indicator
- For recirculating installations, this indicator notifies you when the charcoal filters need replacement, maintaining effective odor filtration.
CleanCover
- The hood's interior features Miele's CleanCover, a sealed, smooth surface that prevents contact with electrical components, enhancing safety and simplifying cleaning.
PowerManagement System
- This system optimizes energy consumption by adjusting the hood's power usage based on operational needs, promoting energy efficiency.
Safety Shut-Off
- For safety and energy conservation, the hood features an automatic shut-off function that turns off the unit after a prolonged period of inactivity.
Customizable Panel
- The hood offers a customizable panel, allowing you to tailor its appearance to match your kitchen's design and aesthetic preferences.
