General Properties
Home Connect® (Wi-Fi Enabled):
Yes
Element Performance
Number of Inductor Elements:
4
1 – Power of Back Left Heating Element:
2,200 W / 3,600 W (In Boost)
2 – Power of Front Left Heating Element:
2,200 W / 3,600 W (In Boost)
3 – Power of Back Right Heating Element:
2,200 W / 3,600 W (In Boost)
4 – Power of Front Right Heating Element:
2,200 W / 3,600 W (In Boost)
Power of Left Area + 1A FlexPlus™ Left Heating Element:
3,300 W / 3,600 W (In Boost)
Power of Right Area + 3A FlexPlus™ Right Heating Element:
3,300 W / 3,600 W (In Boost)
Element Size
Dimension of Back Left Heating Element:
8 1/2" x 7 1/2"
Dimension of Front Left Heating Element:
8 1/2" x 7 1/2"
Dimension of Back Right Heating Element:
8 1/2" x 7 1/2"
Dimension of Front Right Heating Element:
8 1/2" x 7 1/2"
Dimension of FlexPlus™ Left Heating Element:
3 9/16" x 11 1/4"
Dimension of FlexPlus™ Right Heating Element:
3 9/16" x 11 1/4"
Technical Details
Watts (W):
6,240 / 7,200 W
Circuit Breaker (A):
30 A
Conduit:
37" Flexible 3-Wire
Dimensions & Weight
Overall Appliance Dimensions (HxWxD):
3/8"+3 7/8" x 31" x 21 1/4"
Required Cutout Size (HxWxD):
3 7/8" x 28 3/4" x 19 7/8"
Minimum Distance From Counter Front:
2 1/4"
Minimum Distance From Rear Wall:
2"
Warranty
Limited Warranty, Entire Appliance, Parts and Labor:
2 Year
