Technical Details
Installation Type:
Freestanding
Burner Type:
Sealed burners
Type of Grate:
Continuous
Control Type:
Knob/Button
Cooktop Performance
Front Left Burner:
18,000 BTU (Single)
Front Left Center Burner:
12,000 BTU (Single)
Front Right Center Burner:
22,000 BTU (Dual)
Front Right Burner:
18,000 BTU (Single)
Rear Left Burner:
9,500 BTU (Single)
Rear Left Center Burner:
12,000 BTU (Single)
Rear Right Center Burner:
12,000 BTU (Single)
Rear Right Burner:
9,500 BTU (Single)
Oven Performance
Oven Capacity:
4.8 cu. ft. + 2.8 cu. ft.
30" Oven Modes:
Bake, Broil, Conv Bake, Conv Roast, Pizza, Keep Warm
18" Oven Modes:
Bake, Conv Bake, Pizza, Keep Warm
Other Features:
Clock, Timer, Adjust Temperature
Bake Burner Power:
30" Oven: 22,000 BTU; 18" Oven: 14,000 BTU
Broil Burner Power:
30" Oven: 13,500 BTU
Convection:
Convection Fan
Oven Light:
1 in each oven
Oven Racks:
30" Oven: 1 Standard, 1 Telescopic; 18" Oven: 1 Standard, 1 Telescopic
Oven Rack Material:
Chrome Plated
Baking Sheet Size:
30" Oven: Fits 29" x 16"; 18" Oven: Fits 16" x 12 1/2"
Oven Internal Height:
18"
Oven Internal Width:
30" Oven: 23-3/4"; 18" Oven: 12-5/8"
Oven Internal Depth:
19-1/2"
Product Dimensions
Product Dimensions (WxDxH):
47-7/8" x 26-1/2" x 37-1/8"
Product Height (to top of back splash):
37-1/8"
Product Height (to top of side panel):
36"
Product Depth (to bullnose):
26-1/2"
Product Depth (to control board):
26-3/8"
Product Depth (to side panel front):
24"
Adjustable Leg Sizes:
3" Max
Cutout Dimensions (WxDxH):
48" x 24-3/4" x 36"-39"
Package Dimensions (WxDxH):
51-3/8" x 30-1/8" x 45-2/7"
Accessories (Sold Separately)
Reversible Cast Iron Griddle and Grill Plate:
RG1022
LP Conversion Kit (for ARG48):
LPKARG48 (Includes Orifices and Gas Regulator Caps)
