Description
20 Inch Stacked Combination Vaccine Refrigerator/Freezer with 5.47 cu. ft. Total Capacity
The ARG3PV-ADA305AFSTACK combines the ARG3PV auto-defrost vaccine refrigerator with the ADA305AF vaccine freezer, providing 5.47 cu. ft. of total storage capacity. Refrigerator ARG3PV is part of Accucold's Pharma-Vac Performance Series, designed to meet the demanding needs of vaccine storage. This vaccine refrigerator has four adjustable plastic-coated wire shelves, LED lighting, a buffered temperature probe, and a factory-installed antimicrobial handle with naturally occurring silver ions, which help to reduce germ spread and provide a safer, cleaner user experience. Additional features include a power failure alert, door open alarm, sensor failure alarm, and remote alarm contacts. The ADA305AF -25°C Vaccine Freezer utilizes manual defrost operation and features a 3" thick door with a flat door liner, as recommended by the CDC, to prevent users from storing sensitive materials on the door. It has three removable pull-out drawers on fixed wire shelving for convenient storage and is also equipped with high/low temperature and open door alarms. Both units feature front control panels: A microprocessor control panel and a digital thermostat for easy temperature management. It also has a pre-installed probe hole for monitoring equipment, front locks, powerful magnetic gaskets, and hospital-grade cords with 'green dot' plugs for added safety in high-traffic areas.
NOTE: This ships in three boxes and requires minor assembly upon delivery.
Specifications
Overview
Total Capacity:
5.47 cu. ft.
Reversible:
Factory Reversible
US Electrical Safety:
ETL
Canadian Electrical Safety:
ETL-C
Refrigerator-Freezer
Refrigerator - Interior Height:
28 3/8"
Refrigerator - Interior Width:
15 1/4"
Refrigerator - Interior Depth:
11 3/4"
Refrigerator - Capacity:
3.0 cu. ft
Refrigerator - Shelf Type:
Wire
Refrigerator - Shelf Qty:
4
Refrigerator - Temperature Range:
2 to 8°C
Refrigerator - Refrigerant Type:
R600a
Freezer - Interior Height:
23 3/4"
Freezer - Interior Width:
14 1/2"
Freezer - Interior Depth:
17"
Freezer - Capacity:
2.47 cu. ft
Freezer - Shelf Type:
Drawers
Freezer - Temperature Range:
-25° to -15°C
Freezer - Refrigerant Type:
R600a
Dimension & Weight
Width with Door Open:
20 1/4"
Depth with Handle:
24 3/8"
Depth with door at 90°:
40"
Power / Rating
Voltage/Frequency:
115 V AC/60 Hz
Warranty
Parts & Labor Warranty:
1 Year
Compressor Warranty:
5 Years
Features
Refrigerator Features
3.0 Cu. Ft. Capacity
- Interior capacity utilizes adjustable wire shelving to accommodate items of varying sizes
Adjustable Plastic-Coated Wire Shelves
- Designed to accommodate a variety of sizes for flexible storage and improved circulation
Microprocessor Control Panel
- Digital controls with a large LED readout in Celsius or Fahrenheit for intuitive temperature management
Antimicrobial Silver Ion-Coated Handle
- Powder-coated handle with naturally occurring silver ions to help reduce germ spread
+/-1°C Variation
- The published temperature variation is derived from the maximum deviation of an NTC sensor in a 1 oz. vial located nearest the chamber geometric center during a 24 hour test period
Self-Closing Double-Pane Tempered Glass Door
- Provides a full display of stored contents
- Added protection in busy settings; NOTE: Door is not self-closing once reversed to an LHD swing
Interior Light
- Energy efficient LED lighting with internal on/off switch
Audible Power Failure Alarm
- Battery-powered alarm sounds if the power connection is interrupted
Sensor Failure Alarm
- Audible and visual alarm warns if the sensor is disrupted
Password Protection
- Control panel requires password entry to adjust the parameters beyond the set point
Remote Alarm Contacts
- Electronic controller is equipped with a volt-free contact for alarm forwarding to an external remote system (contacts located in the external rear of the unit)
Resettable Min/Max Display
- Control panel provides a readout of the low and high temperatures in 15 minute increments
Automatic Defrost with Adjustable Cycle Defrost
- Adjustable cycle defrost operation ensures the unit avoid temperature spikes and ice buildup
Extended Warranty
- 2 years parts and labor/5 years compressor
Eco-Friendly
- Using environmentally friendly hydrocarbons refrigerants for a greener footprint
Versatile Design
- Compatible with Pyxis®, Omnicell®, and AcuDose RX®
Freezer Features
2.47 Cu. Ft. Capacity
- Provides a compact storage unit that is purpose built, and designed to meet CDC/VFC guidelines
Basket Shelves
- Three slide-out baskets offer convenient storage, with plastic fronts to help protect contents from warmer air when the door is opened
Adjustable Digital Thermostat
- Electronic controls located in the front kickplate for easy & institutive temperature management, with a readout in Fahrenheit or Celsius
-25°C Capable
- Low temperature operation ideal for vaccines, pharmaceuticals, and other sensitive materials
3" Thick Door
- Improved insulation for an efficient performance; NOTE: due to the oversized design, the door does open in its own radius. If installing this freezer against a wall, please see our drawings to ensure adequate space
Sealed Back
- Space-saving design that offers easier cleanability
Manual Defrost
- Static cooling system for reduced temperature fluctuations
No Internal Fans
- Temperature remains more stable with a static cooling system
Other Features
Temperature Alarms
- Visual and audible alarms alert if the interior temperature rises or falls out of set range
Open Door Alarm
- Alarm will sound if the door is left ajar for over 4 minutes (refrigerator) or 1 minute (freezer)
Factory Installed Locks
- Keyed lock conveniently located towards the top of the door for added security (2 keys included for each unit)
Access Ports
- Both units include a pre-installed probe hole to allow easier connection to user-provided monitoring equipment
Hospital Grade Cords with 'Green Dot' Plugs
- Refrigerator & freezer have pre-installed hospital grade cords with 'green dot' plugs for added safety in high traffic areas
Flat Door Liners
- Interior design of both units conforms to CDC guidelines to ensure stable conditions for sensitive materials
Magnetic Door Gaskets
- Quality door gaskets ensure a tight seal for energy savings and improved performance of each unit
Usage Stickers
- Ships with removable warning stickers for "DO NOT UNPLUG," "DO NOT ADJUST TEMPERATURE," and "DO NOT STORE PERSONAL ITEMS"
Space Saving Design
- Allows you to create a full refrigerator-freezer with independent controls in a slim-fitting footprint
Easy Assembly
- Unit ships in three boxes for customer to install the StackRack on the bottom freezer and place and secure the refrigerator on top
100% CFC Free
- Environmentally friendly design without ozone-damaging chemicals
CARB Compliant
- Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
