Description
Pharma-Vac Performance Series 19 Inch Compact Vaccine Refrigerator with 1.94 cu. ft. Capacity
Accucold's Pharma-Vac Performance Series are upright all-refrigerators designed and purpose-built for pharmacy, medication, and vaccine applications to support meeting CDC/VFC guidelines, with a powder-coated silver ion handle that helps prevent germ spread. The ARG2PVLHD has an adjustable control range from +2 to +8°C. The external microprocessor temperature control minimizes door openings, helping to protect stored contents from ambient temperature. The buffered temperature probe is encased in a glycol-filled bottle to better simulate the temperature of the stored product, with an additional sensor that reads air temperature to ensure superior temperature control. The audible and visual temperature alarm sounds if the unit's interior goes out of range. Additional alarms include a power failure alert, door open alarm, and sensor failure alarm. This unit has remote alarm contacts in the rear and a 1/2" probe port on the right side to accept additional monitoring devices. This unit has a hospital-grade cord with a green dot plug for added safety in high-traffic areas.
Inside, the ARG2PVLHD utilizes adjustable cycle defrost operation to avoid temperature spikes. Optimized forced air cooling with one internal fan ensures excellent temperature stability and uniformity with rapid recovery after door openings. The adjustable plastic-coated wire shelves can be positioned at 1/2" increments to accommodate virtually any sized item. This unit includes LED internal lighting with an on/off rocker switch. The interior is constructed from white powder-coated metal to ensure durability and better temperature retention. The factory-installed antimicrobial handle is powder-coated with naturally occurring silver ions that help reduce the spread of germs, allowing for a safer, cleaner user experience. The double-pane tempered glass door ships with a left-hand swing and self-closing function. This model includes a factory-installed lock and has two keys for staff use. Powerful magnetic gaskets ensure a positive seal. Designed with hydrocarbon refrigerant, the ARG2PVLHD provides an energy-efficient solution to vaccine storage. This unit is Pyxis, Omnicell, and AcuDose RX compatible. Additional sizes, as well as solid door options, are also available.
NOTE: Accucold refrigerators are purpose-built to the support meeting the current CDC (Centers for Disease Control) guidelines for the storage of vaccines. Units that end in suffix "456" have been certified to the new NSF 456 standard. As referenced in the current Vaccine Storage and Handling Toolkit, these units incorporate microprocessor controls and forced air circulation for stable operation between 2 and 8°C. For additional temperature assurance, the CDC recommends a calibrated digital data logger (DDL), which can be added with the factory-installed option DL2B or addition of the DL2BKit accessory.
Specifications
Overview
Refrigerator Features
Temperature Range:
2 to 8°C
Electrical Specifications
Voltage/Frequency:
115 V AC/60 Hz
Dimensions & Weight
Height of Cabinet:
22 1/4"
Width with Door Open:
18 7/8"
Depth with Handle:
24 3/4"
Depth with door at 90°:
42 1/2"
Shipping Weight:
104 lbs.
Compressor Step Height:
8 1/4"
Compressor Step Width:
15 1/4"
Compressor Step Depth:
4 1/4"
Warranty
Parts & Labor Warranty:
2 Years
Compressor Warranty:
5 Years
Claims & Certifications
US Electrical Safety:
ETL
Canadian Electrical Safety:
ETL-C
Features
2 Adjustable Plastic-coated Wire Shelves
- Multiple shelf positions spaced at 1/2" to accommodate virtually any size
Automatic Defrost
- Adjustable cycle defrost operation ensures the unit avoid temperature spikes and ice buildup
Interior Light
- Energy efficient LED lighting with internal on/off switch
Temperature Alarm
- Visual and audible alarms alert if the interior temperature rises or falls out of set range
Open Door Alarm
- Alarm will sound if the door is left ajar for over 4 minutes (adjustable from 1-99 minutes)
Audible Power Failure Alarm
- Battery-powered alarm sounds if the power connection is interrupted
Remote Alarm Contacts
- Electronic controller is equipped with a volt-free contact for alarm forwarding to an external remote system (contacts located in the external rear of the unit)
Sensor Failure Alarm
- Audible and visual alarm warns if the sensor is disrupted
Factory-installed Lock
- Keyed lock conveniently located towards the top of the door for added security (2 keys included)
Password Protection
- Control panel requires password entry to adjust the parameters beyond the set point
Access Port
- Includes a pre-installed 1/2" probe hole in the right interior wall to allow easier connection to user-provided monitoring equipment
Antimicrobial Silver Ion-coated Handle
- Powder-coated handle with naturally occurring silver ions to help reduce germ spread
Self-closing Glass Door
- Added protection in busy settings
Microprocessor Control Panel
- Digital controls with a large LED readout in Celsius or Fahrenheit for intuitive temperature management
+/-1°C Variation
- The published temperature variation is derived from the maximum deviation of an NTC sensor in a 1 oz. vial located nearest the chamber geometric center during a 24 hour test period
Adjustable Temperature
- Intuitive controls let you adjust the interior temperature between +2 to +8°C
Resettable Min/Max Display
- Control panel provides a readout of the low and high temperatures in 15 minute increments
Usage Stickers
- Ships with removable warning stickers for "DO NOT UNPLUG," "DO NOT ADJUST TEMPERATURE," and "DO NOT STORE PERSONAL ITEMS"
Durable Interior
- Walls are constructed from white powder coated metal for added strength and improved temperature retention
Matching Freezer
- Pair with Accucold AFZ1PV to create a matching set
Purpose-built Design
- Designed and purpose-built for pharmacy, medication, and vaccine applications to support meeting CDC/VFC guidelines
Versatile Design
- Compatible with Pyxis®, Omnicell®, and AcuDose RX®
Extended Warranty
- 2 years parts and labor/5 years compressor
Eco-Friendly
- Using environmentally friendly hydrocarbons refrigerants for a greener footprint
100% CFC Free
- Environmentally friendly design without ozone-damaging chemicals
CARB Compliant
- Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
Total Capacity
Additional Features
- Double Pane Tempered Glass Door
- Hospital Grade Cord with 'Green Dot' Plug
