Description
40 Inch Insert Hood with 3-Speed
Tornado III meets the most demanding chef’s requirements with multiple blower options. This 15-inch-deep insert features 3-speed electronic LCD controls, dual-level LumiLight LED lighting with TruHue™ technology to match your hood lights to your primary lighting, and an optional wireless remote control to put you in command from up to 15 feet away. Optional, adjustable-depth, stainless steel liners are also available for more flexible installations.
Specifications
Blower Performance
Internal Blower (CBI-290C)*:
200 - 290 CFM, 1.4 - 3 sones
Internal Blower (CBI-390A)*:
200 - 390 CFM, 1.4 - 5 sones
Internal Blower (CBI-600A)*:
240 - 600 CFM, 1.8 - 6 sones
Dual Internal Blower (PBI-1100B)*:
500 -1100 CFM, 3.5 - 8 sones
In-Line Blower (PBN-1000A)*:
500 - 1000 CFM, sones NA
External Blower (CBE-1000)*:
500 - 1000 CFM, sones NA
Features
Lighting:
LumiLight LED with TruHue™, 6Wx2
Wireless Remote Control Option:
Yes, RF
ADA Compliant:
Yes (with remote accessory)
Duct Size (Vertical):
6" Round
Duct Specifications
Vertical Single Internal Blower:
6" Round
Vertical Dual Internal Blower:
10" Round
Vertical In-Line/External Blower:
10" Round
AC Power
Hood w/ CBI-290C:
120V, 60Hz at Max. 1.3A
Hood w/ CBI-390A:
120V, 60Hz at Max. 2.1A
Hood w/ CBI-600A:
120V, 60Hz, Max. 2.6A
Hood w/ PBI-1100B:
120V, 60Hz, Max. 5.8A
Hood w/ PBN-1000A:
120V, 60Hz, Max. 5A
Hood w/ CBE-1000:
120V, 60Hz, Max. 5.8A
Optional Accessories
48” Liner (17-3/8” - 19-7/8” Depth):
AK083480AS
48” Liner (20-1/4” - 22-3/4” Depth):
AK083481AS
Wireless Remote Control:
14000005
Mounting Range
Mounting Height Range:
24" - 36"
Warranty
Features
Blower Sold Separately
- This insert hood is designed to work with a range of compatible internal, in-line, or external blower options (sold separately), allowing you to select the ideal ventilation power and configuration for your kitchen layout and cooking needs.
3-Speed
- Offers precise ventilation control with three blower speeds to match your cooking intensity.
LumiLight LED Lighting with TruHue™
- Energy-efficient LEDs provide bright, natural illumination that blends seamlessly with surrounding lighting.
Dual-Level Lighting
- Toggle between high and low brightness settings for task lighting or ambient mood.
Professional Baffle Filters
- Durable stainless steel filters capture grease efficiently and are dishwasher safe for easy maintenance.
Electronic LCD Controls
- Sleek, intuitive interface allows quick access to fan speeds, lighting, and delay-off functions.
Auto Delay-Off
- Automatically shuts off the fan after a preset time to clear residual air and save energy.
ADA-Compliant Remote Operation
- With the optional wireless remote control (sold separately), this appliance supports convenient, accessible operation from anywhere in the kitchen—ideal for ADA-compliant installations.
Optional Adjustable Liner System
- Optional liner options provide a clean, built-in finish while accommodating both width and depth variations, allowing the insert to integrate seamlessly into a range of custom cabinetry configurations.
Key Features
LumiLight LED Lighting with TruHue™
A bright idea: customize your hoods light to harmonize with the rest of your kitchens lighting at the touch of a button with TruHue™ anywhere from 2700K to 5000K.
