Description
20 Inch Compact Refrigerator with 2.68 cu. ft. Capacity
Accucold offers a wide range of built-in undercounter refrigeration for general-purpose storage in healthcare institutions. The ADA302RFZ is a refrigerator-freezer designed for use in settings complying with ADA guidelines. The ADA302RFZ is sized at 32" high to fit under lower counters, complying with ADA guidelines for accessibility. The fully finished textured white cabinet allows freestanding use, while the front-breathing system means this unit can be built-in with minimum clearance. A factory-installed lock provides convenient access and security, perfect for high-traffic environments. The user-reversible door is 3" thick to ensure proper insulation and unit efficiency, with a handle included for added convenience. This unit comes with a right-angle cord to allow for added placement options without added depth.
Inside, the ADA302RFZ features an all-white 2.68 cu. ft. interior for easy cleaning, with static manual defrost operation and a dial thermostat. An automatic LED light illuminates the interior for full visibility. Three spill-proof adjustable glass shelves offer flexible storage options, and a removable clear crisper drawer holds additional items as needed. The door includes three removable racks. This unit includes a compact freezer compartment with an interior swing door, perfect for ice cube trays, ice packs, or additional supplies in need of freezing. With its compact size and convenient features, the ADA302RFZ is the perfect unit for doctor's offices, nurses' stations, clinics, and other healthcare settings in need of an easy-fitting ADA Compliant refrigerator-freezer.
Note: This product is intended for a wide variety of basic storage applications. Storage of high-value vaccines, life science materials, and medical/clinical biologicals require a product offering tighter temperature control and/or alarms, monitoring, and backup. For more information, browse Accucold's purpose-built line or contact product specialists at 1-888-4-MED-LAB.
Specifications
Overview
Compressor Step Height:
6 1/4"
Compressor Step Width:
16 1/4"
Compressor Step Depth:
6"
Refrigerator-Freezer Features
Crisper Finish:
Transparent
Refrigerator - Shelf Type:
Glass
Refrigerator - Shelf Qty:
3
Refrigerator - Full Door Shelves:
3
Refrigerator - Temperature Range:
35-46° F
Refrigerator - Refrigerant Type:
R600a
Refrigerator - Interior Height:
17 1/2"
Refrigerator - Interior Width:
16 1/4"
Refrigerator - Interior Depth:
17"
Freezer - Interior Height:
5 3/4"
Freezer - Interior Width:
16 1/4"
Freezer - Interior Depth:
11 1/4"
Electrical Specifications
Voltage/Frequency:
115 V AC/60 Hz
Dimensions and Weight
Height of Cabinet:
31 3/4"
Width with Door Open:
20 1/4"
Depth with Handle:
24 3/8"
Depth with door at 90°:
40 1/4"
Warranty
Parts & Labor Warranty:
1 Year
Compressor Warranty:
5 Years
Claims & Certifications
Energy Usage/Year:
259.0kWh/year
US Electrical Safety:
ETL
Canadian Electrical Safety:
ETL-C
Features
3 Adjustable Glass Shelves
- Three adjustable spill-proof glass shelves for optimal storage in the 2.68 cu. ft. interior
Slide-out Drawer
- Removable clear crisper drawer
Door Shelves
- Three removable door racks for additional storage of bottles and other taller items
Freezer Compartment
- Interior freezer compartment offers convenient storage of ice cube trays, ice packs, and other healthcare supplies
Factory Installed Lock
- Located towards the top of the door for easy access and to provide added security of unit (2 keys included)
Manual Defrost
- Static cooling system for added efficiency
Interior Light
- Front-located LED light ensures entire interior is lit when door opens
Adjustable Thermostat
- Dial thermostat located inside for easy temperature management
Reversible Door
- User-reversible door swing for added flexibility to best accommodate your setting
3" Thick Door
- Improved insulation for an efficient performance; NOTE: due to the oversized design, the door does not open in its own radius. If installing this freezer against a wall, please see our drawings to ensure adequate space
Sealed Back
- Space-saving design that offers easier cleanability
Built-in Capable
- Front-breathing design lets you make the best use of space by installing your appliance under the counter
100% CFC Free
- Environmentally friendly design with no ozone-damaging chemicals
CARB Compliant
- Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
Total Capacity
Additional Features
- Fully Finished White Cabinet
